Ubiquiti Networks
Ubiquiti Networks U6-PLUS WiFi 6 access point
Ceiling-mounted WiFi 6 access point covers 140 m², supports 300+ clients, four spatial streams, PoE powered, single GbE port
- # of Users300+
- Standards802.11a/b/g/n/ac/ax (WiFi 6)
- WiFi GenerationWi-Fi 6
- Wireless Data Rates802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5,
- SecurityWPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
- Antenna2.4 GHz 2 x 2 (DL/UL MU-MIMO) 5 GHz 2 x 2 (DL/UL MU-MIMO)
Options U6+
- Supports 300+ simultaneous devices for busy offices
- WiFi 6 with four spatial streams boosts throughput
- 140 m indoor range covers large open areas
- Single GbE port with PoE simplifies installation
- Compact 160 mm ceiling mount fits discreetly
Compact ceiling WiFi 6 access point
The U6-PLUS is a ceiling-mounted indoor access point that supports the WiFi 6 standard and handles over 300 concurrent clients. It is built for small and medium businesses that need reliable wireless coverage across roughly 140 square metres. The unit draws power through a single PoE connection and uplinks via one GbE RJ45 port.
Dual-band 2×2 MU-MIMO with four spatial streams
The radio configuration provides 2.4 GHz and 5 GHz bands each running 2×2 downlink and uplink MU-MIMO, yielding four spatial streams in total. This layout is the single specification that determines whether the AP can deliver the throughput and client density your environment requires.
Sustained operation in extended temperatures
The hardware is rated for continuous use from -30 °C to 60 °C with humidity up to 95 % non-condensing. Transmit power holds at 23 dBm on both bands during prolonged load, and the polycarbonate-aluminium chassis with ABS-SGCC mount maintains structural stability without active cooling.
Highlights
- Supports 300+ simultaneous devices for busy offices
- WiFi 6 with four spatial streams boosts throughput
- 140 m indoor range covers large open areas
- Single GbE port with PoE simplifies installation
- Compact 160 mm ceiling mount fits discreetly
Specifications
| Brand | Ubiquiti Networks |
|---|---|
| Series | WIFI Access points |
| Model | U6-PLUS |
| # of Users | 300+ |
| Standards | 802.11a/b/g/n/ac/ax (WiFi 6) |
| WiFi Generation | Wi-Fi 6 |
| Wireless Data Rates | 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) |
| Security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
| Antenna | 2.4 GHz 2 x 2 (DL/UL MU-MIMO) 5 GHz 2 x 2 (DL/UL MU-MIMO) |
| Transmitted Power | 2.4 GHz 23 dBm 5 GHz 23 dBm |
| Mounting Location | Indoor |
| Operating Range | Indoor: Up to 140m, Outdoor: Up to 140m |
| Interface | (1) GbE RJ45 port |
| LAN Ports | (1) GbE RJ45 port |
| Power Supply | Power method PoE |
| Temperature | -30 to 60° C (-22 to 140° F) |
| Humidity | 5 to 95% noncondensing |
| Dimensions | Ø160 x 33 mm (Ø6.3 x 1.3") |
| Weight | Without mount: 338 g (0.8 lb) With mount: 413 g (0.9 lb) |
| Features | BSSID 8 per radio VLAN 802.1Q Advanced QoS Per-user rate limiting Guest traffic isolation Supported Zero-wait DFS Yes* *Supported with upcoming firmware versions. Concurrent clients 300+ |
| Shipping weight | 0.59 kg |
| Package size | 180 × 178 × 53 mm |
Other versions of this model
5 more in the same range
Same family, different memory, cooler or clock — compare before you commit.
Ubiquiti Networks
Ubiquiti Networks U6-LR-US WiFi 6 long-range access point
- 802.11a/b/g/n/ac/ax…
- 802.11a 6, 9, 12, 1…
$140.99
0.00163264BTC
In stock
Ubiquiti Networks
Ubiquiti Networks U6-IW Wi-Fi 6 in-wall access point
- 300+
- 802.11a/b/g/n/ac/ax…
$148.99
0.00172528BTC
In stock
Ubiquiti Networks
Ubiquiti Networks U6-Mesh WiFi 6 access point
- 300+
- 802.11a/b/g/n/ac/ax…
$152.99
0.0017716BTC
In stock
Ubiquiti Networks
Ubiquiti Networks U6-MESH-PRO-US WiFi 6 access point
- 250+
- 802.11a/b/g/n/ac
$175.99
0.00203794BTC
In stockQuestions about this item
What does the 140 m² coverage figure mean once the U6+ is mounted on a real ceiling?
The 140 m² (1,500 ft²) figure is the indoor coverage radius the manufacturer cites for the U6+ when installed on a ceiling in typical conditions.
What does the single GbE RJ45 port cap in practice?
The single GbE RJ45 uplink limits the wired backhaul to 1 Gbps, so aggregate wireless throughput cannot exceed that wired bottleneck.
What does the Ø160 x 33 mm size mean for fitting the U6+ into a ceiling tile?
The unit is 160 mm in diameter and 33 mm thick, so it fits a standard ceiling cut-out and sits 1.3 inches below the tile surface.
