Tripp Lite 1U rack drawer with 19 inch LCD, keyboard and touchpad, 8 port Cat5 KVM with IP access

Tripp Lite

Tripp Lite B070-008-19-IP 8-Port Cat5 KVM Switch 19" LCD 1U IP Remote Access

SKU CH-YJXK-YXY5X MPN B070-008-19-IP

An 8-port Cat5 KVM switch with a built-in 19-inch LCD, keyboard and touchpad in a 1U drawer, supporting local and IP remote access for two simultaneous users

  • TypeD-Sub, USB, PS/2
  • Computer Connections8-Port Remote
  • Temperature-20 to 60 C (-4 to 140 F)
  • Humidity0 to 80% RH, Non-Condensing
  • Power FeaturesNominal Input Voltage(s) Supported: 100V AC; 110V AC; 115V A
  • FeaturesControl computers/servers locally or via LAN, WAN or Interne

Computer Connections 8-Port Remote

  • Control 8 servers locally or remotely via IP access
  • 19" LCD displays up to 1366 x 768 resolution
  • Cat5 cabling extends server connections up to 100 ft
  • 1U rack drawer saves space with integrated keyboard and touchpad
  • Operates in temperatures from -20 to 60 °C

8-Port Cat5 KVM with 19" LCD

The Tripp Lite B070-008-19-IP combines an 8-port KVM switch, a 19-inch LCD screen, keyboard and touchpad in a single 1U rack-mountable drawer. It supports D-Sub, USB and PS/2 computer connections using Cat5e/6/6a cabling for distances up to 100 ft. The unit operates on nominal input voltages from 100V AC to 240V AC with electrical consumption of 30W in line mode and 5W in standby mode. TAA compliance qualifies it for GSA Schedule purchases.

Suited for single-rack server rooms needing local

This console suits administrators who require simultaneous local and IP-based remote control of up to eight servers from one rack location. The 1366 x 768 LCD resolution and single local user port limit its use for operators needing higher display clarity or multiple concurrent local users. Buyers who need more than eight direct computer connections or dual local consoles should look at a different solution.

1366 x 768 maximum video resolution

The integrated 19-inch LCD supports video resolutions up to 1366 x 768, which determines the maximum display clarity available for both local and remote sessions. If your servers output higher resolutions, the console will downscale the image, potentially affecting readability of detailed interfaces. Verify that this resolution meets your monitoring and management requirements before purchase.

Highlights

  • Control 8 servers locally or remotely via IP access
  • 19" LCD displays up to 1366 x 768 resolution
  • Cat5 cabling extends server connections up to 100 ft
  • 1U rack drawer saves space with integrated keyboard and touchpad
  • Operates in temperatures from -20 to 60 °C

Specifications

BrandTRIPP LITE
ModelB070-008-19-IP
TypeD-Sub, USB, PS/2
Computer Connections8-Port Remote
Temperature-20 to 60 C (-4 to 140 F)
Humidity0 to 80% RH, Non-Condensing
Power FeaturesNominal Input Voltage(s) Supported: 100V AC; 110V AC; 115V AC; 120V AC; 127V AC; 140V AC; 200V AC; 208V AC; 220V AC; 230V AC; 240V AC
Electrical Consumption: (Line Mode) 30W / (Standby Mode) 5W
Nominal Input Voltage Description: Internal Switching 100-240 VAC 50/60Hz
Input Frequency: 50/60Hz
Input Current: 120V (1.2A) / 230V (0.7A)
FeaturesControl computers/servers locally or via LAN, WAN or Internet
Occupies just 1U of space in a rack-mountable drawer
Low-cost Cat5 cabling allows longer distances, reduces cable clutter
19” LCD screen supports video resolutions up to 1366 x 768
Simultaneous support for 2 users – 1 local, 1 remote
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
Free Management Software available to Access and Control all of your Tripp Lite NetCommander IP KVM's (B070 and B072 IP series) from a single interface
Fast Virtual Media KVM System patented under Pat. No. US 9,41
Dimensions1.71" x 17.36" x 28.43" (H x W x D)
Weight28.66 lbs.
Package ContentsB070-008-19-IP 1U rackmount console KVM switch with 19” LCD
C13 to 5-15P power cord
Rackmount hardware
CD with owner's manual
Quick start guide
Shipping weight17.89 kg
Package size823 × 597 × 157 mm

Other versions of this model

3 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I verify the 19" LCD is displaying the correct 1366 x 768 resolution after rack-mounting the B070-008-19-IP?

Power on the unit, open the drawer and check the on-screen display menu; it will report the active resolution. If the connected server outputs 1366 x 768, the LCD shows it natively without scaling.

Which cables and adapters must I purchase separately to connect eight servers to the Cat5 ports on this KVM switch?

The package includes the KVM drawer, a C13 to 5-15P power cord, rack-mount hardware and a CD with manuals. You must buy Cat5e/6/6a patch cables and the appropriate USB or PS/2 dongles for each of the eight server ports.

When should I choose the 8-port IP model over a smaller port-count version for my rack?

Select this 8-port model when you need to control up to eight servers from a single 1U drawer with both local LCD/keyboard/touchpad access and simultaneous remote IP access for a second user.
