Silver metal box with 16 RJ45 ports on the front

TP-Link

TP-Link TL-SG1016D 16-port Gigabit network switch

SKU CH-H6MN-Z8MB3 MPN TL-SG1016D

A 16-port Gigabit unmanaged switch with a metal case, fanless operation and energy-efficient technology that cuts power use by up to 40%

  • FormatDesktop/Rackmount
  • StandardsIEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
  • Network Management TypeUnmanaged
  • Uplink Ports16
  • Uplink InterfaceRJ45
  • Primary Ports16 x RJ45

Class 16 port Gigabit Desktop

  • 16 Gigabit ports expand network capacity instantly
  • Plug-and-play setup requires no configuration
  • Fanless metal chassis ensures silent operation
  • Energy-efficient design cuts power use by 40%
  • Auto MDI/MDIX removes need for crossover cables

16-Port Gigabit Unmanaged Switch

The TP-Link TL-SG1016D is a metal-cased Layer 2 switch with sixteen 10/100/1000 Mbps RJ45 ports. It operates without configuration and uses store-and-forward switching with 10 KB jumbo frame support. Innovative energy-efficient technology reduces power consumption by up to 40 percent. The fanless design ensures silent operation in office or server-room environments.

Suits Small Offices Needing Silent Density

This switch fits networks that require sixteen Gigabit connections in a compact desktop or rackmount form factor without fan noise. It is not for administrators who need VLANs, QoS, link aggregation or any Layer 3 routing features. Buyers requiring Power over Ethernet for cameras or access points must choose a different model. Environments exceeding 40 °C ambient temperature are outside the rated operating range.

Sixteen Auto-Negotiation Gigabit Ports

Every port supports 10/100/1000 Mbps auto-negotiation and Auto MDI/MDIX, removing the need for crossover cables. MAC address auto-learning and auto-aging handle traffic forwarding automatically. IEEE 802.3x flow control manages full-duplex congestion while backpressure handles half-duplex links. The non-blocking architecture forwards and filters packets at wire speed across all sixteen ports simultaneously.

Highlights

  • 16 Gigabit ports expand network capacity instantly
  • Plug-and-play setup requires no configuration
  • Fanless metal chassis ensures silent operation
  • Energy-efficient design cuts power use by 40%
  • Auto MDI/MDIX removes need for crossover cables

Specifications

BrandTP-Link
ModelTL-SG1016D
FormatDesktop/Rackmount
StandardsIEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
Network Management TypeUnmanaged
Uplink Ports16
Uplink InterfaceRJ45
Primary Ports16 x RJ45
Primary Port Speed10/100/1000Mbps
Switching MethodStore and Forward
Jumbo Frames10KB
ProtocolsTCP/IP
PoENo
LayerLayer 2 Only
Power100~240VAC, 50/60Hz
Dimensions11.6" x 7.1" x 1.7"
Weight4.88
Temperature0°C to 40°C (32°F to 104°F)
Humidity10% - 90%, Non-condensing
FeaturesInnovative energy-efficient technology saves power up to 40%
Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
32Gbps Switching Capacity
10K Jumbo frame improves performance of large data transfers
Auto-MDI/MDIX eliminates the need for crossover cables
Supports MAC address auto-learning and auto-aging
Store and forward Switching scheme
Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps and 1000Mbps hardware.
P
Package Contents16-Port Gigabit Switch
Power Cord
User Guide
Shipping weight2.16 kg
Package size401 × 251 × 81 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the TL-SG1016D fit in a standard rack or sit on a desk?

The switch measures 11.6" x 7.1" x 1.7" and weighs 4.88, supporting both desktop and rackmount placement.

What is the correct way to connect cables so the 16 RJ45 ports negotiate speed automatically?

Plug each device into any of the 16 RJ45 ports; Auto MDI/MDIX and auto-negotiation handle crossover and 10/100/1000M detection without configuration.

Which parts might need attention after the switch has run continuously in a 0°C to 40°C environment?

The fanless, metal chassis has no moving parts to replace; keep vents clear and operate within the 0°C to 40°C range for long-term reliability.
