Silver 1U rack PDU with two front outlets, three-digit amp meter and status LEDs

Synaccess Networks

Synaccess Networks NP-0201DU 1U Switched Metered PDU 2 Outlets 120V 15A

SKU CH-8DVM-K5R15

A 1U switched metered PDU with two independently controlled 120 V outlets, true RMS current monitoring and remote management via web, Telnet or serial

  • TypeSwitched, Metered
  • Rack Size1U
  • StyleOptional mounting bracket
  • Remote Management ProtocolHTTP/HTTPS/Telnet/SNMP/SMTP/ICMP
  • Front Panel LEDs3-digits AC current meter and Outlet status LEDs
  • CertificationsUL Std 60950-1 by TUV USA
  • True RMS current sensor tracks total amperage per input
  • Two independently switched outlets managed via web, Telnet or serial
  • TLS 1.2 encryption and IP filtering secure remote access
  • Auto-ping and scheduled reboots keep devices responsive
  • UL 60950-1 listed by TUV USA for safety compliance

1U Switched Metered PDU for Remote Outlet Control

The Synaccess Networks NP-0201DU is a 1U rackmount power distribution unit with two independently switched outlets. It serves administrators who need to power-cycle remote servers or network gear over IP or serial links. The unit provides true RMS current metering per input and environment temperature monitoring. It is built for equipment racks where secure, scriptable outlet management is required.

Two Outlets at 120 V with 15 A Input

Each outlet delivers 120 V at 50/60 Hz from a single IEC-320 C14 inlet rated for 15 A maximum input current. The regulatory derated input current is 16 A and total output capacity is 1800 VA. The six-foot cord connects to standard rack PDUs or UPS outputs. Buyers who need more than two switchable outlets or a higher amperage feed should select a different model.

Passive Cooling with Front Current Meter

The PDU operates without internal fans, relying on convection within the rack airflow. A three-digit LED meter on the front panel shows real-time AC current draw across the outlet group. Outlet status LEDs and a link LED give immediate visual confirmation of power state. UL 60950-1 certification by TUV USA and RoHS compliance confirm safety standards for continuous operation.

Highlights

  • True RMS current sensor tracks total amperage per input
  • Two independently switched outlets managed via web, Telnet or serial
  • TLS 1.2 encryption and IP filtering secure remote access
  • Auto-ping and scheduled reboots keep devices responsive
  • UL 60950-1 listed by TUV USA for safety compliance

Specifications

BrandSynaccess
SeriesnetBooter
ModelNP-0201DU
TypeSwitched, Metered
Rack Size1U
StyleOptional mounting bracket
Remote Management ProtocolHTTP/HTTPS/Telnet/SNMP/SMTP/ICMP
Front Panel LEDs3-digits AC current meter and Outlet status LEDs
CertificationsUL Std 60950-1 by TUV USA
ROHSYes
ConnectivityIP Networks or local serial port
Input Voltage120VAC
Input Frequency50/60 Hz
Maximum Input Current15A
Regulatory Derated Input Current16A
Input Connector(s)IEC-320 C14
Cord Length6 ft
Output Voltage120V
Output Frequency50/60Hz
Output Watts (VA)1800
Output Connector(s)NEMA 5-15
Overload ProtectionNo
Operating Environment-5 - 60 ºC
Operating Relative Humidity0 - 95%
Operating Elevation0 - 3000 m
Storage Temperature-20 - 60 ºC
Storage Relative Humidity0 - 95%
Storage Elevation0 - 15000 m
DimensionsL 6.15" x W 5.40" x H 1.75"
Weight3 Lbs

Questions about this item

What does the 1800 VA rating mean for the equipment I can plug into the two outlets?

The unit delivers up to 1800 VA at 120 V, so the combined load of both outlets must stay within that apparent power limit.

What network and local interfaces are available for remote power control?

Management is provided through HTTP, HTTPS, Telnet, SNMP, SMTP and ICMP over IP, plus a local USB serial port for direct access.

What input connection and cord length does the PDU ship with for rack installation?

It comes with a 6 ft cord terminated in an IEC-320 C14 plug for connection to a compatible UPS or wall outlet.
