Black 1U rackmount server chassis with ten front 2.5-inch hot-swap drive bays

Supermicro

Supermicro SYS-1019P-WTR 1U barebone server 10-bay 500W

SKU CH-HVJ1-RQXWQ MPN SYS-1019P-WTR

A 1U rackmount barebone with ten hot-swap 2.5" Sata bays, dual 10 Gigabit LAN, two PCI-E 3.0 x16 slots, one PCI-E 3.0 x8 slot and 500W redundant power for Intel Xeon Scalable processors

  • CPU TypeSingle Socket P (LGA 3647) Intel Xeon Scalable Processors Su
  • CPU SocketLGA 3647
  • North BridgeIntel C622
  • Max Memory SupportedUp to 768GB ECC 3DS LRDIMM, 192GB ECC RDIMM, DDR4 up to 2666
  • Memory Type Supported2666 / 2400 / 2133 MHz ECC DDR4 SDRAM
  • Serial ATA10 x SATA 600
  • Single-socket LGA 3647 supports Xeon Scalable up to 205W TDP
  • 10 hot-swap 2.5" SATA bays for dense storage capacity
  • Dual 10GBase-T LAN ports with Intel X722 and X557 controllers
  • 500W redundant power supplies with PMBus for reliable uptime
  • Up to 768GB ECC DDR4-2666 across six DIMM slots

1U barebone for single-socket Xeon

The Supermicro SYS-1019P-WTR is a 1U rackmount barebone built around a single LGA 3647 socket for Intel Xeon Scalable processors. It targets operators who need dense compute in a standard rack with integrated storage and networking. The platform suits database processing, storage nodes and general data-centre workloads where a compact form factor is required.

Memory capacity up to 768 GB ECC

Six DIMM slots accept DDR4 ECC RDIMM up to 192 GB or 3DS LRDIMM up to 768 GB at speeds of 2666, 2400 or 2133 MHz. Ten hot-swap 2.5-inch SATA3 bays provide internal storage with RAID 0, 1, 5 and 10 support. Dual 10GBase-T ports handle high-throughput networking, while the 500 W redundant supply with PMBus delivers headroom for CPUs rated between 70 W and 205 W TDP.

Expansion slots and front-access bays

Two full-height full-length PCI-E 3.0 x16 slots and one low-profile x8 slot allow add-in cards such as GPUs, NICs or storage controllers. Front-mounted hot-swap bays let operators replace drives without leaving the cold aisle. Rear I/O includes two USB 3.0 ports, two USB 2.0 ports, a serial port, dual 10GBase-T RJ45 and a dedicated IPMI LAN port for remote management via the Aspeed AST2500 BMC.

Highlights

  • Single-socket LGA 3647 supports Xeon Scalable up to 205W TDP
  • 10 hot-swap 2.5" SATA bays for dense storage capacity
  • Dual 10GBase-T LAN ports with Intel X722 and X557 controllers
  • 500W redundant power supplies with PMBus for reliable uptime
  • Up to 768GB ECC DDR4-2666 across six DIMM slots

Specifications

BrandSUPERMICRO
ModelSYS-1019P-WTR
CPU TypeSingle Socket P (LGA 3647)
Intel Xeon Scalable Processors
Support CPU TDP 70-205W
CPU SocketLGA 3647
North BridgeIntel C622
Max Memory SupportedUp to 768GB ECC 3DS LRDIMM, 192GB ECC RDIMM, DDR4 up to 2666 MHz
Memory Type Supported2666 / 2400 / 2133 MHz ECC DDR4 SDRAM
Serial ATA10 x SATA 600
SATA RAIDRAID 0/1/5/10
GPU/VPUAspeed AST2500 BMC
PCI Express2 x PCI-E 3.0 x16 (FHFL) slots
1 x PCI-E 3.0 x8 (LP) slot
Number of LANDual 10GBase-T LAN with Intel X722 + X557
Max. LAN SpeedDual 10 Gigabit
Hot-Swap Bays10 x Hot-swap 2.5" SATA3 drive bays
COM1
Rear USB2 x USB 3.0 ports
2 x USB 2.0 ports
RJ452 x RJ45 10GBase-T LAN ports
1 x RJ45 dedicated IPMI LAN port
Max. Power500W Redundant Power Supplies with PMBus
FeaturesSingle socket P (LGA 3647) supports Intel Xeon Scalable Processors
Up to 768GB ECC 3DS LRDIMM, up to DDR4-2666 MHz; 6 x DIMM slots
2 x PCI-E 3.0 x16 (FHFL) slots, 1 x PCI-E 3.0 x8 (LP) slot
10 x Hot-swap 2.5" SATA3 drive bays; 2 x NVMe w/ AOC option
2 x 10GBase-T ports with Intel X722 + X557
1 x VGA, 2 x COM, 2 x USB 3.0, 2 x USB 2.0
2 x SuperDOM (Disk on Module) ports
500W Redundant Platinum Level power supplies
Form Factor1U Rackmount
Dimensions1.70" x 17.20" x 23.50"
Weight15.50 lbs.
Shipping weight17.28 kg
Package size810 × 605 × 191 mm

Questions about this item

Will my existing DDR4-2400 ECC RDIMMs work in the 6 DIMM slots of this Supermicro SYS-1019P-WTR?

Yes, the board supports DDR4 at 2666, 2400 and 2133 MHz, so your 2400 MHz ECC RDIMMs are compatible and will run at their rated speed.

How can I verify the dual 10GBase-T ports and the dedicated IPMI LAN are active after first boot?

Check the rear panel link LEDs on the two RJ45 10GBase-T ports and the separate IPMI RJ45; then log into the Aspeed AST2500 BMC web interface to confirm each interface shows a valid connection.

Which items ship with the barebone and which must I source separately?

The 1U chassis, X11SPW-TF motherboard, 500W redundant PSUs, 10 hot-swap 2.5" SATA trays and backplane are included; you must add a LGA 3647 Xeon Scalable CPU, DDR4 ECC memory and storage drives.
