Gray 14 inch all-in-one panel PC with flat IP65 front and capacitive touchscreen

partaker

partaker Z10-I5 6200U-8G256G 14" AI edge system

SKU CH-EKRJ-3RDSE

Fanless 14" IP65 panel PC with 10-point capacitive touch, Core i5-6200U, 8 GB DDR4, 256 GB SSD, dual LAN, dual COM, HDMI, VGA, Windows 11 Pro

  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 11 Pro
  • CPU TypeIntel Core i5 6th Gen
  • CPU NameIntel Core i5-6200U
  • GPU/VGA TypeIntel HD Graphics 520

CPU Type Intel Core i5 6th Gen

CPU Name Intel Core i5-6200U

Memory Capacity 8GB DDR4

SSD 256GB

HDD None

  • IP65 front panel resists dust and water in harsh environments
  • 10-point capacitive touch enables precise multi-finger control on 14-inch screen
  • Fanless aluminium cooling runs silently with 0 to 50°C operating range
  • Dual LAN plus HDMI, VGA, 2 COM and 4 USB ports connect diverse industrial gear
  • Windows 11 Pro pre-installed on 8GB DDR4 and 256GB SSD for instant deployment

14" IP65 Fanless Panel PC

The Partaker Z10-I5 6200U-8G256G is an all-in-one industrial panel PC built for continuous operation in harsh environments. Its 14 inch TFT LED display offers 1600 x 900 resolution with a 10-point projected capacitive touchscreen protected to IP65 on the front panel. A 6th Gen Intel Core i5-6200U processor with Intel HD Graphics 520 drives Windows 11 Pro in a fanless aluminum chassis rated for 0 to 50 °C with SSD.

Check power, mounting and expansion needs

Verify that a 12 V DC supply is available and that the 346.3 x 231.3 x 42.7 mm chassis fits your cut-out of 340.3 x 225.3 mm. The system ships with 8 GB DDR4 and a 256 GB SSD; internal expansion uses one mSATA slot and one 2.5 inch SATA bay plus a Mini PCIe slot with SIM holder for wireless modules. Dual LAN, two USB 3.0, two USB 2.0, HDMI, VGA, two COM ports and audio jacks cover most legacy and modern peripherals.

Sustained load in a sealed enclosure

Passive aluminum cooling dissipates heat without moving parts, so acoustic signature stays at zero during 24/7 workloads. The CPU throttles only when the chassis approaches its 50 °C limit, maintaining stability for long data-logging or HMI sessions. Auto power recovery restarts the unit after an outage, and the watchdog timer can reset a hung process without manual intervention.

Highlights

  • IP65 front panel resists dust and water in harsh environments
  • 10-point capacitive touch enables precise multi-finger control on 14-inch screen
  • Fanless aluminium cooling runs silently with 0 to 50°C operating range
  • Dual LAN plus HDMI, VGA, 2 COM and 4 USB ports connect diverse industrial gear
  • Windows 11 Pro pre-installed on 8GB DDR4 and 256GB SSD for instant deployment

Specifications

ModelZ10-I5 6200U-8G256G
Form FactorAll-in-One
ColorGray
Operating SystemWindows 11 Pro
CPU TypeIntel Core i5 6th Gen
CPU NameIntel Core i5-6200U
GPU/VGA TypeIntel HD Graphics 520
Memory Capacity8GB DDR4
SSD256GB
HDDNo
Screen Size14"
TouchscreenYes

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What is included in the box and what must I source separately?

The box contains the Partaker Z10 Panel PC, a power supply, a power cord, embedded buckle kits and a warranty card. The unit ships with 8GB DDR4 and a 256GB SSD already installed. Additional DDR3L SODIMM modules up to 16GB total, a 2.5" SATA drive or a Mini PCIe WiFi/4G module with SIM are optional upgrades you would buy separately.

Which memory and storage configuration should I choose for this model?

This SKU is fixed at 8GB DDR4 and a 256GB SSD. The board accepts two DDR3L SODIMM slots (1333/1600) for a maximum of 16GB, plus one mSATA SSD and one 2.5" SATA SSD/HDD bay if you need more capacity later.

What does the 14" IP65 1600x900 touchscreen mean for daily industrial use?

The 14 inch front panel is rated IP65 against dust and water jets, supports 10-point projected capacitive touch with 200 million touch durability, and delivers 1600x900 resolution at 200 cd/m² brightness with a 400:1 contrast ratio for readable operation in 0-50°C environments.
