KEHIPI
KEHIPI YC-3610T 36V 10A 360W power adapter
Delivers regulated 36V DC at up to 10A for LED strips, CCTV cameras and security systems, with built-in cooling and short-circuit protection
- ColorMetallic
- Dimensions21.0 in x 11.0 in x 5.0 in
- Weight0.64 ounces
- Delivers 360W DC power for LED strips and security systems
- Adjustable output voltage by 10% for precise strip matching
- Built-in fan and vented metal case give high heat dissipation
- circuit, over-voltage and high-voltage protection safeguards connected devices
- Universal 110V-220V input with selector switch for worldwide use
36 V 10 A regulated supply for LED
The KEHIPI YC-3610T delivers DC 36 V at up to 10 A with a maximum output of 360 W. It is built for indoor use with LED pixel strips such as WS2811, WS2812B and WS2813 as well as CCTV cameras and automation equipment. A metal enclosure with a built-in fan and ventilation holes provides heat dissipation.
Verify AC selector and screw terminals before wiring
The unit accepts AC 110 V or 220 V at 50/60 Hz via an input voltage switch that must be set correctly before power is applied. Output connections use screw terminals with a 2.5 mm hole diameter for +V, -V and an adjustable +V ADJ trimmer. Operating temperature range is -10 to 50 °C and storage range is -20 to 60 °C at 10 to 95 % humidity non-condensing.
Adjustable output trim
The +V ADJ terminal allows approximately 10 % output voltage adjustment to compensate for cable drop. Protection features cover short circuit, high voltage and over-voltage conditions. The adapter carries CCC, FCC and CE compliance marks and ships as a single unit weighing 1.85 pounds.
Highlights
- Delivers 360W DC power for LED strips and security systems
- Adjustable output voltage by 10% for precise strip matching
- Built-in fan and vented metal case give high heat dissipation
- circuit, over-voltage and high-voltage protection safeguards connected devices
- Universal 110V-220V input with selector switch for worldwide use
Specifications
| Brand | Aclorol |
|---|---|
| Model | YC-3610T |
| Part Number | YC-3610T |
| Color | Metallic |
| Dimensions | 21.0 in x 11.0 in x 5.0 in |
| Weight | 0.64 ounces |
Questions about this item
What is included in the package and what must be purchased separately?
The package includes one 36V 10A switching power supply. AC input cables and LED strips such as WS2811, WS2812B or WS2813 are not included and must be bought separately.
How do I select the correct input voltage for my region?
Use the built-in switch to choose between AC 110V and 220V before connecting to mains power to avoid damaging the unit.
What does the 360W rating mean when powering LED strips in a real installation?
It delivers up to DC 36V at 10A continuously, suitable for WS2811, WS2812B or WS2813 strips within the -10 to 50°C operating range, with short-circuit, high-voltage and over-voltage protection.
