Jansicotek
Jansicotek HDMI Matrix Switch 4x4 4K@30Hz 10.2Gbps IR Remote Black
Connects four HDMI sources to four displays at up to 4K@30Hz with IR remote and front-panel switching
- TypeHDMI Switchers
- Changer TypeHDMI Switch/Extender
- ColorBlack
- Ports4x4 Matrix
- MatrixYes
- AudioYes
- Route four sources to four displays independently
- 4K@30Hz YUV 4:2:0 via HDMI 1.4 at 10.2Gbps
- 1080p@60Hz and 3D video supported
- PCM, Dolby AC3, DTS 5.1, DTS 7.1 and DSD audio pass-through
- IR remote and front-panel switching with 3-5s changeover
Four-by-four HDMI matrix
The Jansicotek HDMI Matrix Switch 4x4 routes four HDMI sources to four displays, supporting switching and splitting in home theatres, classrooms, retail spaces and control rooms. It handles resolutions up to 4096 x 2160 with YUV 4:2:0 4K at 30 Hz and 1080p at 60 Hz. An IR remote and front-panel buttons provide control, with a three-to-five-second delay when changing routes. Audio passes through in PCM, Dolby AC3, DTS 5.1, DTS 7.1 and DSD formats.
Cables and sources to verify
Confirm each source device outputs HDMI 1.4 signals within the supported resolution and refresh-rate limits. Use AWG26 HDMI 1.4 standard cables no longer than eight metres on both input and output sides. The unit does not perform EDID management, so source devices must negotiate compatible formats without assistance. Ensure your sources can deliver 3D or 3440 x 2160 at 30 Hz if those modes are required.
Integration into an AV system
The matrix fits into multi-zone installations where four sources must reach four screens independently or simultaneously. It frees up manual cable swapping and works alongside splitters, extenders and converters from the same ecosystem. Power the unit, connect sources and displays within the eight-metre cable limit, then use the IR remote or front buttons to route any input to any output. No EDID configuration is needed, simplifying deployment in conference rooms, video walls and digital-signage setups.
Highlights
- Route four sources to four displays independently
- 4K@30Hz YUV 4:2:0 via HDMI 1.4 at 10.2Gbps
- 1080p@60Hz and 3D video supported
- PCM, Dolby AC3, DTS 5.1, DTS 7.1 and DSD audio pass-through
- IR remote and front-panel switching with 3-5s changeover
Specifications
| Type | HDMI Switchers |
|---|---|
| Changer Type | HDMI Switch/Extender |
| Color | Black |
| Ports | 4x4 Matrix |
| Matrix | Yes |
| Audio | Yes |
| Maximum Resolutions | 4096 x 2160 |
Questions about this item
Does the Jansicotek 4x4 matrix include the HDMI cables I need to connect four sources and four displays?
The unit itself is supplied without HDMI cables. You will need eight cables — four for the inputs and four for the outputs — each rated for HDMI 1.4 and no longer than 8 metres if you use AWG26 wire.
When should I choose the 4K@30Hz YUV 4:2:0 mode instead of 1080p@60Hz on this switcher?
Select 4K@30Hz YUV 4:2:0 when your source and display both support 3440x2160 at 30 Hz and you need the higher pixel count. Use 1080p@60Hz for smoother motion on 1080p screens or when cable runs approach the 8-metre limit.
What does the 10.2 Gbps bandwidth figure mean for my 4K@30Hz setup?
The 10.2 Gbps limit carries 4K@30Hz in YUV 4:2:0 colour sampling, plus 3D formats and audio such as PCM, Dolby AC3, DTS 5.1, DTS 7.1 and DSD. It will not pass full 4:4:4 4K@60Hz signals.
