iStarUSA Inc.
iStarUSA Inc. T-C25HD-P server accessory 2.5" SATA hot-swap rack plastic
A trayless hot-swap rack holds 2.5" SATA drives up to 12.5mm thick in a plastic chassis measuring .70" x 3.50" x 5.31"
- TypeHot-swap Rack
- SpecificationsRoHS Compliance: Yes Standard Drive Bays: None Hotswap HDD T
- FeaturesSupport SATA I/II/III 6.0Gb/s Hard Drive Energy Saving on Us
- Hot-swap 2.5" SATA drives at 6.0 Gb/s
- Trayless plastic design saves space and cost
- Supports drives up to 12.5 mm thickness
- RoHS compliant for safer materials
- Compact .70" x 3.50" x 5.31" form factor
2.5" SATA hot-swap rack
The iStarUSA T-C25HD-P is a trayless hot-swap rack that accepts 2.5" SATA I/II/III hard drives or SSDs up to 12.5 mm thick. Its plastic chassis and handle keep cost low while supporting 6.0 Gb/s data rates. The unit is RoHS compliant and built to custom dimensions of .70" x 3.50" x 5.31". It suits server builders who need quick drive changes without trays.
Verify bay clearance and SATA backplane
Before ordering, confirm that your chassis can accommodate the rack's .70" height, 3.50" width and 5.31" depth. The host system must provide a SATA backplane or cabling that matches the drive interface. Ensure the power and data connectors align with the drive position in the bay. Drives thicker than 12.5 mm will not fit the slot.
Plastic tray-less design for daily swaps
The all-plastic construction reduces weight and eliminates metal tray handling during drive swaps. Drives slide directly into the opening, so insertion and removal are fast and tool-free. The plastic handle offers a grip for frequent changes without scratching adjacent components. The rack carries no drive bays of its own, relying on the host enclosure for structural support.
Highlights
- Hot-swap 2.5" SATA drives at 6.0 Gb/s
- Trayless plastic design saves space and cost
- Supports drives up to 12.5 mm thickness
- RoHS compliant for safer materials
- Compact .70" x 3.50" x 5.31" form factor
Specifications
| Brand | iStarUSA |
|---|---|
| Model | T-C25HD-P |
| Type | Hot-swap Rack |
| Specifications | RoHS Compliance: Yes Standard Drive Bays: None Hotswap HDD Type:: 2.5" SATA I/II/III Material of Handle: Plastic Material of Main Chassis: Plastic Dimensions: 0.70" x 3.50" x 5.31" |
| Features | Support SATA I/II/III 6.0Gb/s Hard Drive Energy Saving on Using 2.5" HDDs or SSD Support standard 2.5" HDD / SSD up to 12.5mm thickness Plastic Structure with Trayless Design for Best Cost Custom size |
| Shipping weight | 0.45 kg |
| Package size | 152 × 102 × 25 mm |
Questions about this item
Does the T-C25HD-P come with any 2.5" SATA drives or mounting screws?
The rack is a trayless plastic carrier that accepts standard 2.5" SATA I/II/III drives up to 12.5 mm thick; drives and any mounting hardware are separate purchases.
I only see one model listed — are there different capacity or size versions of the T-C25HD-P to choose from?
The T-C25HD-P is offered as a single custom-size unit measuring 0.70" x 3.50" x 5.31"; no alternative capacities or form-factor variants are available for this model.
The headline says SATA 6.0 Gb/s — what transfer speed will I actually see once a drive is installed in a server?
The rack supports SATA I, II and III signalling up to 6.0 Gb/s; real-world throughput depends on the drive and controller used.
