iStarUSA Inc. D-260HNSL-C246-1 2U barebone server
2U rackmount barebone with six hot-swap 3.5″ bays, LGA 1151 socket for Xeon E-2100 CPUs, four DDR4 slots up to 64 GB, dual Intel gigabit LAN, three PCIe 3.0 slots and 500 W PSU
- Form Factor2U Rackmount
- MaterialZinc-Coated Steel
- WorkloadEdge Server
- CPU TypeSupports Intel Xeon E-2100 Processors
- CPU SocketLGA 1151
- North BridgeIntel C246
- Supports Xeon E-2100 processors via LGA 1151 socket
- Dual-channel DDR4 up to 64 GB with ECC support
- Six trayless 3.5" hot-swap bays for rapid drive changes
- Eight SATA 600 ports plus three PCIe 3.0 expansion slots
- 500 W single power supply in 2U zinc-coated steel chassis
Edge server barebone for Xeon E-2100
The iStarUSA D-260HNSL-C246-1 is a 2U rackmount chassis designed for edge workloads. It accepts Intel Xeon E-2100 processors in an LGA 1151 socket with the Intel C246 chipset. Four 288-pin slots support dual-channel DDR4 up to 64 GB with ECC. Six trayless hot-swap bays and one internal 3.5-inch bay provide dense storage. A 500 W single power supply is included.
Thermal behaviour under continuous edge loads
The zinc-coated steel chassis and 2U height give a fixed airflow path for the included 500 W PSU and passive CPU cooler. Sustained compute tasks will raise internal temperatures until the system fans reach maximum speed. No liquid-cooling support or redundant PSU option exists, so thermal headroom is limited to the single supply and stock fan curve. Builders running constant 100 % CPU utilisation should monitor inlet temperatures closely.
Assembly steps and common pitfalls
Install the CPU, memory and drives before sliding the unit into a rack; the hot-swap trays accept 3.5-inch SATA drives without tools. Memory must be unregistered DDR4 ECC or non-ECC UDIMM; registered DIMMs will not post. The single PCIe 3.0 x16 slot shares bandwidth with the x8 and x4 slots, so only one full-length add-in card fits physically. Rear-panel video uses HDMI or DisplayPort from the processor graphics; a discrete GPU blocks those outputs.
Highlights
- Supports Xeon E-2100 processors via LGA 1151 socket
- Dual-channel DDR4 up to 64 GB with ECC support
- Six trayless 3.5" hot-swap bays for rapid drive changes
- Eight SATA 600 ports plus three PCIe 3.0 expansion slots
- 500 W single power supply in 2U zinc-coated steel chassis
Specifications
| Brand | iStarUSA |
|---|---|
| Model | D-260HNSL-C246-1 |
| Form Factor | 2U Rackmount |
| Material | Zinc-Coated Steel |
| Workload | Edge Server |
| CPU Type | Supports Intel Xeon E-2100 Processors |
| CPU Socket | LGA 1151 |
| North Bridge | Intel C246 |
| Memory Slots | 4 x 288Pin |
| Installed Memory Size | No Memory Installed |
| Max Memory Supported | 64GB |
| Channel Supported | Dual Channel |
| ECC Supported | Yes |
| Registered | No |
| Serial ATA | 8 x SATA 600 |
| PCI Express | 1 x PCIe 3.0 x16 1 x PCIe 3.0 x8 1 x PCIe 3.0 x4 |
| First LAN | 2 x RJ45 GLAN by Intel® i210&I219LM |
| Max. LAN Speed | 1 Gigabit |
| 3.5" Bays | 1 |
| Hot-Swap Bays | 6 |
| COM | 1 |
| VGA | 1 |
| Rear USB | 4 x USB 3.0 |
| RJ45 | 2 |
| Other Ports | 1 x HDMI, 1 x DisplayPort |
| Max. Power | 500W Single |
| Features | 2U Rackmount with 500W PSU 6 x 3.5" Trayless Hot-Swappable Drive Bays Supports Intel Xeon E-2100 Processors Supports Dual channel DDR4 2666/2400 ECC and non-ECC U DIMM max 64 GB Support 8x SATA3 by C246 Supports 1x PCIe 3.0 x16, 1x PCIe 3.0 x8, 1x PCIe 3.0 x4 Supports Intel i210&i219LM Supoorts 4 x Half Height Expansion Slot |
| Dimensions | 3.48" x 20.66" x 19.00" |
| Weight | 30.00 lbs. |
| Shipping weight | 15.88 kg |
| Package size | 610 × 584 × 203 mm |
Questions about this item
How loud or hot does the 500W power supply run when the server operates 24/7?
The unit ships with a 500W single power supply; acoustic and thermal output will depend on the Xeon E-2100 processor and memory configuration you install.
Which components must I supply before the barebone will boot?
You must add an LGA 1151 Xeon E-2100 CPU, DDR4 288-pin ECC or non-ECC UDIMMs up to 64GB, and storage drives for the six hot-swap 3.5-inch bays and the single internal 3.5-inch bay.
Will my existing PCIe 3.0 add-in cards fit the expansion slots?
The chassis provides one PCIe 3.0 x16, one PCIe 3.0 x8 and one PCIe 3.0 x4 slot, so any PCIe 3.0 card that matches those lane widths will install directly.
