GIGABYTE R262-ZA2 barebone server 2U AMD EPYC 7003 16 DIMM 4 x 3.5" bay
2U rackmount barebones server supporting AMD EPYC 7003 processors with 16 DDR4 DIMM slots, four 3.5-inch NVMe/SATA/SAS hot-swap bays, and dual PCIe 4.0 GPU capacity
- Form Factor2U Rackmount
- WorkloadGeneral Purpose Server
- CPU TypeAMD EPYC 7003/7002 Series
- CPU SocketSocket SP3
- Installed CPUNo CPU Installed
- Max Processors1
- Supports AMD EPYC 7003 processors with up to 64 cores and 128 threads
- Eight-channel DDR4 architecture across 16 DIMM slots enables up to 4TB memory capacity
- Four 3.5" hot-swappable bays accept Gen4 NVMe, SATA or SAS drives
- PCIe 4.0 expansion with up to two dual-slot GPUs plus OCP 3.0 networking
- Hardware root of trust and Aspeed AST2500 management provide platform security and remote control
2U single-socket EPYC barebone
The GIGABYTE R262-ZA2 is a 2U rackmount barebone server designed for single AMD EPYC 7003 or 7002 series processors in an SP3 socket. It targets general-purpose data-centre workloads that require high core counts and extensive I/O within a compact chassis. Builders who need dual-socket scaling or support for newer processor generations will not find that capability here.
Thermals and power headroom
The platform supports CPUs with a configurable TDP up to 240 W and provides 16 DDR4 DIMM slots across eight memory channels. PCIe 4.0 lanes totalling 128 per socket feed the expansion slots and four hot-swappable 3.5-inch drive bays that accept NVMe, SATA or SAS media. No specific fan or acoustic figures are supplied for normal operation.
Expansion and management bundle
The barebone includes an Aspeed AST2500 baseboard management controller and dual 1 Gb/s LAN ports via an Intel I350-AM2 adapter. PCIe layout provides four full-height full-length Gen4 x16 or x8 slots, one full-height half-length Gen4 x16 slot, one full-height half-length Gen3 x16 or x8 slot, two low-profile Gen4 x8 slots, plus OCP 3.0 Gen4 x16 and OCP 2.0 Gen3 x8 mezzanine slots. A single M.2 M-key slot supports 2280 or 22110 cards. NVIDIA-Certified status and hardware root-of-trust support are validated for this configuration.
Highlights
- Supports AMD EPYC 7003 processors with up to 64 cores and 128 threads
- Eight-channel DDR4 architecture across 16 DIMM slots enables up to 4TB memory capacity
- Four 3.5" hot-swappable bays accept Gen4 NVMe, SATA or SAS drives
- PCIe 4.0 expansion with up to two dual-slot GPUs plus OCP 3.0 networking
- Hardware root of trust and Aspeed AST2500 management provide platform security and remote control
Specifications
| Brand | GIGABYTE |
|---|---|
| Model | R262-ZA2 |
| Form Factor | 2U Rackmount |
| Workload | General Purpose Server |
| CPU Type | AMD EPYC 7003/7002 Series |
| CPU Socket | Socket SP3 |
| Installed CPU | No CPU Installed |
| Max Processors | 1 |
| CPU Features | Single processor, 7nm technology Up to 64 cores, 128 threads cTDP up to 240W |
| Memory Slots | 16 x 288Pin |
| Installed Memory Size | No Memory Installed |
| Max Memory Supported | 4TB |
| Memory Type Supported | Up to 3200*/2933 MT/s *Follow BIOS setting and memory QVL if running 3200 MT/s with 2DPC. |
| Channel Supported | 8 Channel |
| Registered | Yes |
| Installed HDD | No Storage Installed |
| M.2 | 1 x M.2 slot: - M-key - PCIe Gen4 x4 - Supports 2280/22110 cards |
| GPU/VPU | Aspeed AST2500 |
| PCI Express | 4 x FHFL PCIe Gen4 x16 and x8 slots 1 x FHHL PCIe Gen4 x16 slot 1 x FHHL PCIe Gen3 x16 or x8 slot 2 x LP PCIe Gen4 x8 slots 1 x OCP 3.0 Gen4 x16 slot 1 x OCP 2.0 Gen3 x8 mezzanine slot |
| First LAN | Intel I350-AM2 |
| Max. LAN Speed | 1 Gigabit |
| Hot-Swap Bays | Front side: 4 x Gen4 NVMe/SATA/SAS hot-swappable trays Rear side: 2 x 2.5" SATA/SAS hot-swappable bays |
| Buttons | 1 x NMI button 1 x Reset button |
| LEDs | 1 x Power button with LED 1 x ID button with LED 2 x LAN activity LEDs 1 x Storage activity LED 1 x System status LED |
| Front USB | 2 x USB 3.0 |
| VGA | 1 |
| Rear USB | 2 x USB 3.0 |
| RJ45 | 2 |
| Other Ports | 1 x MLAN |
| System Compatibility | Citrix Hypervisor 8.2.0 or later Red Hat Enterprise Linux 8.3 or later Red Hat Enterprise Linux 9.0 or later SUSE Linux Enterprise Server 12 SP5 or later SUSE Linux Enterprise Server 15 SP2 or later Ubuntu 18.04.5 LTS or later Ubuntu 20.04 LTS or later Ubuntu 22.04 LTS or later VMware ESXi 6.7 Update3 P03 or later VMware ESXi 7.0 Update1 or later VMware ESXi 8.0 or later Windows Server 2016 (X2APIC/256T not supported) Windows Server 2019 Windows Server 2022 |
| Fans | 4 x 80x80x38mm (16,300rpm), 2-ball |
| Temperature | Operating temperature: 10°C to 35°C Non-operating temperature: -40°C to 60°C |
| Humidity | Operating humidity: 8%-80% (non-condensing) Non-operating humidity: 20%-95% (non-condensing) |
| Dimensions | 3.44" x 17.24" x 28.74" |
| Weight | 39.24 lbs. |
| Shipping weight | 20.00 kg |
| Package size | 982 × 588 × 268 mm |
Questions about this item
How do I install the CPU in the SP3 socket and what step is commonly missed?
Align the processor with the Socket SP3 keying, lower the carrier frame, then torque the captive screws in the labelled diagonal sequence to ensure even pressure across all 64 cores.
Which components will need replacement first during the server's service life?
The Aspeed AST2500 management GPU and system fans are the only active silicon shipped pre-installed; plan to swap fan modules before bearing wear affects airflow over the 240 W cTDP envelope.
What thermal limit appears first when both PCIe Gen4 x16 GPU slots run sustained compute loads?
The 240 W processor cTDP ceiling is reached before the dual-slot GPU power budget, so total platform power throttles at the CPU package limit.
