GIGABYTE R113-C10-AA02-L1002 barebone server EPYC 4464P 64GB DDR5 1TB
1U rackmount barebones server with AMD EPYC 4464P 12-core CPU, 64 GB DDR5-4800 memory and 1 TB SSD storage
- Form Factor1U Rackmount
- WorkloadGeneral Purpose Server
- CPU TypeSupports AMD EPYC 4004 Series, AMD Ryzen 7000 / 9000 Series
- CPU SocketAM5
- Installed CPUAMD EPYC 4464P
- CPU FeaturesTDP up to 105W Note: Overclocking not supported due to therm
- 12-core EPYC 4464P handles parallel workloads
- 64GB DDR5 ECC memory protects data integrity
- PCIe Gen5 x16 slot enables high-speed expansion
- Dual Intel 1GbE plus management LAN ensures connectivity
- 1U rackmount fits dense server deployments
1U Rackmount Server with EPYC 4464P
This 1U rackmount barebones server arrives with an AMD EPYC 4464P processor installed. The 12-core, 24-thread CPU operates at a TDP up to 105W and is paired with 64GB of DDR5 UDIMM memory running at 4800 MT/s. A 1TB WD Black SN850X SSD is also pre-installed, providing immediate storage capacity. The platform uses the AMD B650E chipset and supports dual-channel memory architecture with ECC capability.
Suited for General Purpose Workloads
This configuration targets general purpose server deployments needing a compact, pre-validated platform. Builders who require overclocking headroom should look elsewhere, as thermal limits prevent it. Organisations needing more than one PCIe x16 add-in card or more than a single M.2 slot will find the expansion limited. The dual 1Gb/s LAN ports and dedicated management LAN fit standard network environments.
64GB DDR5 and 1TB Storage Headroom
The installed 64GB DDR5 4800 MT/s memory fills two of four UDIMM slots, leaving room to scale within the dual-channel limit. The single M.2 slot accepts 2242 or 2280 form factors at PCIe Gen5 x4 speeds, while SATA RAID 0/1/10 supports additional 2.5-inch drives. The FHHL PCIe x16 Gen5 slot accommodates one full-height accelerator or network card. Memory speeds drop to 3600 MT/s when all four slots are populated.
Highlights
- 12-core EPYC 4464P handles parallel workloads
- 64GB DDR5 ECC memory protects data integrity
- PCIe Gen5 x16 slot enables high-speed expansion
- Dual Intel 1GbE plus management LAN ensures connectivity
- 1U rackmount fits dense server deployments
Specifications
| Brand | GIGABYTE |
|---|---|
| Model | R113-C10-AA02-L1002 |
| Form Factor | 1U Rackmount |
| Workload | General Purpose Server |
| CPU Type | Supports AMD EPYC 4004 Series, AMD Ryzen 7000 / 9000 Series |
| CPU Socket | AM5 |
| Installed CPU | AMD EPYC 4464P |
| CPU Features | TDP up to 105W Note: Overclocking not supported due to thermal limitation. |
| North Bridge | AMD B650E |
| Memory Slots | 4 x 288Pin |
| Installed Memory Size | No Memory Installed |
| Memory Type Supported | AMD Ryzen 9000: UDIMM: Up to 5600 MT/s (1DPC), 3600 MT/s (2DPC) AMD EPYC 4004 / Ryzen 7000: UDIMM: Up to 5200 MT/s (1DPC), 3600 MT/s (2DPC) |
| Channel Supported | Dual Channel |
| ECC Supported | Yes |
| Installed HDD | No Storage Installed |
| SATA RAID | RAID 0/1/10 |
| M.2 | 1 x M.2 (2242/2280), PCIe Gen5 x4, from CPU |
| GPU/VPU | Aspeed AST2600 |
| PCI Express | 1 x PCIe x16 (Gen5 x16) FHHL slot, from CPU |
| First LAN | 2 x 1Gb/s LAN ports (2 x Intel I210-AT) Support NCSI function 1 x 10/100/1000 Mbps Management LAN |
| Max. LAN Speed | 1 Gigabit |
| 2.5" Bays | 2 x 2.5" SATA bays |
| Hot-Swap Bays | 2 x 2.5" SATA Front hot-swap bays |
| Buttons | 1 x Power button 1 x Reset button |
| LEDs | 1 x Power LED 2 x LAN activity LEDs 1 x Storage activity LED 1 x System status LED |
| Front USB | 2 x USB 3.2 Gen1 ports (Type-A) |
| COM | 1 |
| VGA | 1 |
| Rear USB | 2 x USB 3.2 Gen1 ports (Type-A) |
| RJ45 | 2 |
| Other Ports | Rear 1 x MLAN 1 x ID button with LED |
| Max. Power | Single 400W 80 PLUS Gold power supply |
| System Compatibility | EPYC 4004 Series: Ubuntu 22.04 Ubuntu 24.04 Windows Server 2022 Ryzen 9000/7000 Series: Windows 10 21H2 Windows 11 |
| Fans | 3 x 40x40x56mm (29,700rpm) |
| Temperature | Operating temperature: 10°C to 35°C Non-operating temperature: -40°C to 60°C |
| Humidity | Operating humidity: 8%-80% (non-condensing) Non-operating humidity: 20%-95% (non-condensing) |
| Dimensions | 430 x 43.5 x 393.2 mm |
| Package Contents | 1 x R113-C10-AA02 1 x CPU heatsink |
| Shipping weight | 7.71 kg |
| Package size | 584 × 521 × 152 mm |
Questions about this item
Which DDR5 UDIMM speeds will the installed EPYC 4464P CPU actually run at in this server?
The EPYC 4464P supports UDIMM up to 5200 MT/s with one DIMM per channel and 3600 MT/s with two DIMMs per channel across the four 288-pin slots.
Can I keep my existing 2.5-inch SATA drives and use the onboard RAID controller?
Yes, the 2.5-inch drive bays connect to the SATA controller that provides RAID 0, 1 and 10.
How do I confirm the management LAN is active after the server is racked?
Connect the dedicated 10/100/1000 Mbps management port; the Aspeed AST2600 BMC will present its web interface once the port detects link.
