Black compact barebone Mini PC with fanless design

GIGABYTE

GIGABYTE 6BXJDDXXWMR-00 barebone server Intel Celeron N4500 16GB DDR4

SKU CH-NCKT-VKQRB MPN 6BXJDDXXWMR-00

A compact fanless barebone with an Intel Celeron N4500, one DDR4 SO-DIMM slot supporting 16 GB at 2933 MHz, an M.2 2280 slot for PCIe x2 or SATA storage, and HDMI 2.0b for 4K HDR output

  • Form FactorCompact
  • CPU TypeIntel Celeron
  • Installed CPUIntel Celeron N4500
  • Max Processors1
  • CPU Features2 core (TDP 6W)
  • Memory Slots1 x 240Pin
  • Fanless operation with 6W Intel Celeron N4500 processor
  • Ultra-compact 0.67L chassis measuring 56.22x103x116.52mm
  • Single DDR4 2933 SO-DIMM slot supports up to 16GB
  • M.2 2280 slot accepts PCIe x2 or SATA SSD plus 2.5 inch SATA bay
  • HDMI 2.0b outputs 4K at 60Hz with HDR10 support

Compact fanless barebone

This GIGABYTE BRIX barebone arrives as a 0.67-litre chassis with an Intel Celeron N4500 dual-core processor already fitted. The 6 W TDP allows completely passive cooling, so the system runs silently in noise-sensitive locations. A single SO-DIMM slot accepts DDR4 2933 memory up to 16 GB, and one M.2 2280 slot plus a 2.5-inch SATA bay provide flexible storage options. HDMI 2.0b, Gigabit LAN and dual-band wireless complete the connectivity set.

Suitable for always-on edge deployments

The low-power CPU and fanless design suit digital signage, kiosk controllers, thin-client desktops and light home-theater PCs that must operate 24/7 without acoustic disturbance. Buyers who need multi-threaded compute, discrete graphics or more than one memory channel should look at larger platforms. The single SO-DIMM limit also rules out dual-channel bandwidth requirements.

Memory ceiling decides the build

Maximum supported capacity is 16 GB of DDR4 2933 in a single slot, so the total system memory is fixed at that level. If the intended workload demands more RAM, this chassis cannot accommodate it and a different barebone must be chosen.

Highlights

  • Fanless operation with 6W Intel Celeron N4500 processor
  • Ultra-compact 0.67L chassis measuring 56.22x103x116.52mm
  • Single DDR4 2933 SO-DIMM slot supports up to 16GB
  • M.2 2280 slot accepts PCIe x2 or SATA SSD plus 2.5 inch SATA bay
  • HDMI 2.0b outputs 4K at 60Hz with HDR10 support

Specifications

BrandGIGABYTE
ModelGB-BMCE-4500C
Part Number6BXJDDXXWMR-00
Form FactorCompact
CPU TypeIntel Celeron
Installed CPUIntel Celeron N4500
Max Processors1
CPU Features2 core (TDP 6W)
Memory Slots1 x 240Pin
Installed Memory SizeNo Memory Installed
Max Memory Supported16GB
Memory Type SupportedDDR4 2933
Installed HDDNo Storage Installed
M.21 x M.2 slot (2280_storage) PCIe X2/SATA
1 x PCIe M.2 NGFF 2230 A-E key slot occupied by the WiFi+BT card
GPU/VPUIntel UHD Graphics 605
Onboard AudioRealtek ALC255
First LANRealtek 8111HS
Max. LAN Speed1 Gigabit
WLANDual Band Wireless-802.11 AC
Front USB1 x USB3.0
1 x USB3.0 type C
Front Audio Ports1 x Headphone jack
1 x Microphone jack
DisplayPort1 x mini DisplayPort (1.2a)
Rear USB2 x USB 3.0
RJ451 x 2.5 GbE RJ45
Other Ports1 x HDMI(2.0a)
Max. PowerInput: AC 100-240V
Output: DC 19V/3.42A, 65W
TemperatureOperating Temperature: 0°C to +35°C
Storage Temperature: -20°C to +60°C
Dimensions2.21" x 4.06" x 4.59"
Shipping weight1.23 kg
Package size279 × 178 × 76 mm

Questions about this item

What DDR4 SO-DIMM do I need to add so the single 240-pin slot reaches the 16 GB limit?

Install one DDR4 2933 SO-DIMM up to 16 GB; the board has a single 240-pin slot and no memory is installed from the factory.

Will my existing 2.5-inch 7 mm or 9.5 mm SATA drive fit in the internal bay?

Yes, the chassis accepts one 2.5-inch drive at 7.0 mm or 9.5 mm thickness on the onboard 6 Gbps SATA 3 connector.

How can I confirm the fanless cooler is keeping the 6 W Celeron N4500 within limits after assembly?

Enter the BIOS hardware monitor and verify the CPU temperature remains below the thermal throttle point while the system idles and under load.
