Compact desktop firewall appliance, light grey metal casing, nine RJ-45 ports on front, power and console ports at rear

Fortinet

Fortinet FG-71F-BDL-950-36 firewall appliance

SKU CH-6HPQ-V4R9H MPN FG-71F-BDL-950-36

Desktop firewall appliance with 9 Gigabit Ethernet ports, 128 GB SSD, 1.5 M concurrent sessions and 3-year FortiCare Premium plus FortiGuard UTP

  • TypeWired
  • Form FactorDesktop
  • Encryption StandardSSL
  • System MemoryInternal Storage: 1 x 128 GB SSD
  • Ports1 x USB Port 1 x Console Port 2 x GE RJ45 WAN Ports 1 x GE R
  • Simultaneous Sessions35000

Model FortiGate 71F

Option w/ FortiCare Premium, FortiGuard Unified Threat Protection (3-Y)

  • Compact desktop design fits tight spaces
  • 10 Gbps firewall throughput handles heavy traffic
  • 9 RJ-45 ports connect WAN, DMZ and internal segments
  • 5 million concurrent sessions support growing networks
  • 3-year FortiCare Premium with FortiGuard UTP included

Desktop firewall for small sites

The FortiGate 71F is a desktop appliance that ships with a three-year FortiCare Premium and FortiGuard Unified Threat Protection bundle. It targets small to medium-sized businesses and distributed enterprises that need integrated security services without a rack-mount chassis.

Gigabit ports set the throughput ceiling

Nine RJ-45 interfaces provide two WAN links, one DMZ, two FortiLink uplinks and five internal ports, all limited to 10/100/1000Base-T speeds. Firewall throughput reaches 10 Gbps with 1518-byte packets and 6 Gbps with 64-byte packets, so aggregate traffic above the gigabit line rate will queue at the port level.

128 GB SSD stores logs and signatures

The internal 128 GB drive holds the operating system, threat signatures and local logs for the 35 000 simultaneous session capacity. Heavy logging or long retention periods will fill the drive, and the appliance has no additional storage bays for expansion.

Highlights

  • Compact desktop design fits tight spaces
  • 10 Gbps firewall throughput handles heavy traffic
  • 9 RJ-45 ports connect WAN, DMZ and internal segments
  • 5 million concurrent sessions support growing networks
  • 3-year FortiCare Premium with FortiGuard UTP included

Specifications

BrandFortinet
SeriesFortiGate 71F Series
ModelFortiGate 71F w/ FortiCare Premium and FortiGuard Unified Threat Protection (UTP)
Part NumberFG-71F-BDL-950-36
TypeWired
Form FactorDesktop
Encryption StandardSSL
System MemoryInternal Storage: 1 x 128 GB SSD
Ports1 x USB Port
1 x Console Port
2 x GE RJ45 WAN Ports
1 x GE RJ45 DMZ Port
2 x GE RJ45 FortiLink Ports
5 x GE RJ45 Internal Ports
Simultaneous Sessions35000
WAN Ports2 x RJ-45
VPNFirewall Throughput (1518 / 512 / 64 byte UDP packets): 10/10/6 Gbps
Firewall Latency (64 byte UDP packets): 2.54 µs
Firewall Throughput (Packets Per Second): 9 Mpps
Concurrent Sessions (TCP): 1.5 M
New Sessions/Second (TCP): 35 000
Firewall Policies: 5000
IPsec VPN Throughput (512 byte): 6.1 Gbps
Gateway-to-Gateway IPsec VPN Tunnels: 200
Client-to-Gateway IPsec VPN Tunnels: 500
SSL-VPN Throughput: 405 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode): 200
SSL Inspection Throughput (IPS, avg. HTTPS): 700 Mbps
SSL Inspection CPS (IPS, avg. HTTPS): 3 500
SSL Inspection C
Throughput1Gbps - 2.5Gbps
OS SupportFortiOS
CertificationsUSGv6/IPv6
ComplianceFCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Power InputPower Rating: 12VDC, 3A
Power Required: Powered by External DC Power Adapter, 100–240V AC, 50/60 Hz
Maximum Current: 100VAC/1.0A, 240VAC/0.6A
Power Consumption (Average / Maximum): 17.2 W / 18.7 W
FeaturesFortiGuard Unified Threat Protection (UTP) with FortiCare Premium bundle offers foundational security services tailored for small to medium-sized businesses and distributed enterprises. This edition provides the essential tools needed to defend against common and emerging cyber threats of malware, phishing, and network intrusions, ensuring a safe and secure digital environment for business operations.
Dimensions1.5 x 8.5 x 6.3 (inches)
Weight2.23 lbs (1.01 kg)
Shipping weight2.06 kg
Package size287 × 213 × 122 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I choose the FG-71F-BDL-950-36 bundle or a standalone FG-71F unit?

The FG-71F-BDL-950-36 includes the hardware plus a 36-month FortiCare Premium and FortiGuard Unified Threat Protection subscription, so security services are active from day one.

What does the 1.25 GB/s firewall throughput mean for my office network?

That figure represents the maximum inspection speed for 1518-byte UDP packets; real-world throughput with mixed traffic and security features enabled will be lower.

How do the GE RJ45 ports limit my WAN and LAN design?

The appliance provides two GE RJ45 WAN ports, one DMZ port, two FortiLink ports and five internal ports, all capped at 1 Gbps per link.
