Compact fanless desktop firewall appliance in matte grey metal with seven RJ45 ports visible on the front face

Fortinet

Fortinet FG-71F-BDL-809-12 firewall appliance

SKU CH-NN8D-XQ8BV MPN FG-71F-BDL-809-12

Desktop firewall with 7 × 1 GbE ports, 128 GB SSD, 10 Gbps throughput and 1-year FortiCare Premium plus FortiGuard Enterprise Protection

  • TypeWired
  • Form FactorDesktop
  • Encryption StandardSSL
  • System MemoryInternal Storage: 1 x 128 GB SSD
  • Ports7 x 1GbE RJ45
  • Simultaneous Sessions35000

Model FortiGate 71F

Option w/ FortiCare Premium, FortiGuard Enterprise Protection (1-Y)

  • Enterprise protection with FortiGuard AI-Powered Security Services
  • High throughput enabled by patented ASIC and FortiOS
  • 7 x 1GbE RJ45 ports for flexible connectivity
  • Compact fanless desktop design fits branch offices
  • 128 GB internal SSD storage included

Compact desktop firewall for branch offices

The FortiGate 71F series delivers a Next-Generation Firewall and SD-WAN appliance in a fanless desktop chassis. It is aimed at enterprise branch locations and mid-sized businesses that need integrated threat protection and secure connectivity without rack infrastructure. The bundle includes FortiCare Premium support and FortiGuard Enterprise Protection for one year.

Fanless build with seven RJ45 ports

Silent operation comes from the fanless design, while the 128 GB internal SSD provides local log and configuration storage. Seven Gigabit RJ45 interfaces include two dedicated WAN ports, giving flexible uplink options for dual-ISP or failover scenarios. An external 12 V DC adapter powers the unit from 100–240 V AC mains with a typical draw of 17.2 W.

Throughput shaped by 1 GbE interfaces

Firewall throughput reaches 10 Gbps for 1518-byte packets and 6 Gbps for 64-byte packets, with latency of 2.54 µs and 9 Mpps packet rate. The 1 GbE ports cap real-world WAN and LAN speeds at 1 Gbps, so environments that need multi-gigabit inspection will require a platform with faster interfaces. Concurrent session capacity sits at 1.5 million TCP sessions.

Highlights

  • Enterprise protection with FortiGuard AI-Powered Security Services
  • High throughput enabled by patented ASIC and FortiOS
  • 7 x 1GbE RJ45 ports for flexible connectivity
  • Compact fanless desktop design fits branch offices
  • 128 GB internal SSD storage included

Specifications

BrandFortinet
SeriesFortiGate 71F Series
ModelFortiGate 71F w/ FortiCare Premium and FortiGuard Enterprise Protection (1-Y)
Part NumberFG-71F-BDL-809-12
TypeWired
Form FactorDesktop
Encryption StandardSSL
System MemoryInternal Storage: 1 x 128 GB SSD
Ports7 x 1GbE RJ45
Simultaneous Sessions35000
WAN Ports2 x GE RJ45 WAN Ports
VPNFirewall Throughput (1518 / 512 / 64 byte UDP packets): 10/10/6 Gbps
Firewall Latency (64 byte UDP packets): 2.54 µs
Firewall Throughput (Packets Per Second): 9 Mpps
Concurrent Sessions (TCP): 1.5 M
New Sessions/Second (TCP): 35 000
Firewall Policies: 5000
IPsec VPN Throughput (512 byte): 6.1 Gbps
Gateway-to-Gateway IPsec VPN Tunnels: 200
Client-to-Gateway IPsec VPN Tunnels: 500
SSL-VPN Throughput: 405 Mbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode): 200
SSL Inspection Throughput (IPS, avg. HTTPS): 700 Mbps
SSL Inspection CPS (IPS, avg. HTTPS): 3 500
SSL Inspection C
Throughput1Gbps - 2.5Gbps
OS SupportFortiOS
CertificationsUSGv6/IPv6
ComplianceFCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Power InputPower Rating: 12VDC, 3A
Power Required: Powered by External DC Power Adapter, 100–240V AC, 50/60 Hz
Maximum Current: 100VAC/1.0A, 240VAC/0.6A
Power Consumption (Average / Maximum): 17.2 W / 18.7 W
Dimensions1.5 x 8.5 x 6.3 (inches)
Weight2.23 lbs (1.01 kg)
Shipping weight2.27 kg
Package size287 × 211 × 122 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What throughput does the 1GbE RJ45 interface deliver in practice?

The seven 1GbE RJ45 ports support firewall throughput of 10 Gbps for 1518 byte packets, 10 Gbps for 512 byte packets and 6 Gbps for 64 byte UDP packets.

What physical space and mounting does the desktop unit need?

The fanless desktop chassis measures 1.5 x 8.5 x 6.3 inches and weighs 2.23 lbs; it sits on a shelf or desk with no rack rails required.

How is the appliance powered up and what step is often missed?

Connect the external 12 V DC 3 A adapter to a 100–240 V AC outlet, then plug the DC jack into the unit; the step often missed is verifying the adapter LED before powering on.
