Yellow handheld tone generator and probe kit with angled bed-of-nails clips and RJ11 plug

FLUKE networks

FLUKE networks 26000900 Pro3000 Analog Tone and Probe tester

SKU CH-8F0A-75ZYP MPN 26000900

Tones and traces wires on inactive networks up to 16 km with five distinct cadences for pair identification

  • SpecificationsPro3000 Analog Toner Specifications User interface: Slide sw
  • FeaturesUse the SmartTone capability of the Pro3000 Tone Generator t

Option Pro3000 Tone & Probe Kit

  • SmartTone technology gives five distinct tones for exact pair identification
  • Loud tone reaches up to 16 km (10 miles) in most cables
  • Adjustable-volume speaker lets you hear tone through drywall and wood
  • Angled bed-of-nails clips and RJ11 plug connect without adapters
  • Checks continuity and polarity with dual-color LED indication

Fluke Pro3000 Analog Tone & Probe Kit

The Fluke Networks Pro3000 kit tones and traces wire on inactive networks up to 16 km. It includes a tone generator with angled bed-of-nails clips and an RJ11 plug, plus a probe with an adjustable-volume speaker. SmartTone technology provides five distinct cadences for exact pair identification. Dual LEDs indicate continuity and polarity status.

Ideal for telephone and data cable installers

Technicians who need to locate cables behind drywall or wood and identify specific pairs in multi-pair cables will benefit. Users requiring digital signal analysis, active network testing, or fibre optic tracing should look at other instruments. This kit is designed for analog tone generation on de-energised copper wiring only.

1000 Hz tone frequency with five cadences

The generator outputs a nominal 1000 Hz tone in solid or alternating modes. SmartTone shifts the cadence among five distinct patterns when the far end of a pair is shorted, letting you isolate the correct wires. This specific frequency and cadence control is the key specification for verifying compatibility with existing tracing workflows.

Highlights

  • SmartTone technology gives five distinct tones for exact pair identification
  • Loud tone reaches up to 16 km (10 miles) in most cables
  • Adjustable-volume speaker lets you hear tone through drywall and wood
  • Angled bed-of-nails clips and RJ11 plug connect without adapters
  • Checks continuity and polarity with dual-color LED indication

Specifications

BrandFluke Networks
Model26000900
SpecificationsPro3000 Analog Toner Specifications
User interface:
Slide switch selects Continuity or Tone Mode
Push button switch selects SOLID, ALT or OFF
Tone mode LED
Continuity/Polarity LED
Solid Frequency: 1000 Hz nominal
Alternating Frequency: 1000/1500 Hz nominal
Over Voltage Protection: 60 Vdc in Toner/Polarity Mode
Output Power in Tone Mode: 8 dbm into 600 ohms
Output Voltage Level in Continuity Mode: 8 Vdc with fresh battery
Battery: 9V alkaline
Temperature: Operating: -20° C to 60° C, Storage: -40° C to 70° C
Pro3000 Analog Probe specifications
User interface:
ON/OFF pushbutton
Volume d
FeaturesUse the SmartTone capability of the Pro3000 Tone Generator to identify the right pair.
When touching the wires together and momentarily shorting the far end of a cable pair, the SmartTone technology will change the cadence of the tone generated.
This tone change you hear through the probe positively verifies the correct wire pair. SmartTone provides five distinct tones for exact pair identification.
Loud large speaker amplifies tone through walls, enclosure, wood or plaster
Easy-to-use adjustable volume control dial
"Quick-twist" tip for easy replacement
Free spare tip inside Pro3000
Shipping weight0.91 kg
Package size413 × 305 × 103 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What type of cable or network jack does the 26000900 kit connect to for tracing?

The kit includes angled bed-of-nails clips for direct wire access and an RJ11 plug that connects directly to telephone jacks without needing adapters.

Can the Pro3000 tone generator be used on live network circuits?

The tone generator is designed for non-active networks only; it sends a loud tone up to 16 km in most cables but must not be connected to energized circuits.

How does the SmartTone feature confirm I have the correct wire pair?

When you short the far end of a pair, the tone cadence changes distinctly, providing one of five unique tones to verify exact pair identification.
