Silver 1U rack-mount switch with 24 front RJ-45 ports and two QSFP28 slots

Extreme Networks

Extreme Networks 552024W 24-port 90W PoE network switch

SKU CH-3C22-SY23C MPN 552024W

Managed 24-port Gigabit switch delivers up to 90W per port via 802.3bt PoE with two QSFP28 stacking ports and base software included

  • Network Management TypeManaged
  • Management Interface24 x 10/100/1000BASE-T 802.3bt (90W) ports Full / Half-Duple
  • PoEYes
  • PoE Ports24 x PoE
  • PoE Power Budget1x715W: 494W 2x715W: 1079W 1x1100W: 879W 1 x 2000W @ 100-120
  • Max Power Consumption2480W

Model 5520-24W

Struck-through versions exist but are not stocked here.

  • 24 ports deliver up to 90W PoE each for high-power devices
  • 2 stacking QSFP28 ports enable high-speed switch interconnects
  • MACsec-capable hardware encrypts traffic at line rate
  • Cloud-managed via Extreme Platform ONE or ExtremeCloud IQ
  • 1U rack height fits dense cabinet deployments

Managed 24-Port PoE Switch

The Extreme Networks 5520-24W is a managed switch delivering 90W PoE on all 24 RJ-45 ports. It targets enterprise networks that need high-density power for wireless access points, IP cameras, and VoIP endpoints. The platform supports cloud, on-premises, or fabric-based management through Extreme Platform ONE and ExtremeCloud IQ. MACsec-capable hardware secures data on every link.

Build Integration and Uplink Options

Two unpopulated QSFP28 stacking ports provide high-speed uplinks or switch stacking without consuming front-panel ports. A dedicated out-of-band management port, serial console, USB Micro-B console, and two USB-A ports give multiple paths for configuration and firmware storage. One VIM slot allows future I/O expansion. The 1U chassis fits standard racks at 44 mm height and 441 mm width.

Upgrade Path and Power Scaling

This model replaces switches limited to 802.3at power levels, enabling 90W per port for pan-tilt-zoom cameras and high-performance access points. PoE budget scales with the installed power supplies: a single 715W unit delivers 494W, while dual 2000W units at 200-240VAC provide 2160W. Organisations staying with lower-power PoE+ devices or needing fewer than 24 powered ports will not utilise the full capacity.

Highlights

  • 24 ports deliver up to 90W PoE each for high-power devices
  • 2 stacking QSFP28 ports enable high-speed switch interconnects
  • MACsec-capable hardware encrypts traffic at line rate
  • Cloud-managed via Extreme Platform ONE or ExtremeCloud IQ
  • 1U rack height fits dense cabinet deployments

Specifications

BrandExtreme Networks
Series5520 Series
Model5520-24W
Part Number5520-24W
Network Management TypeManaged
Management Interface24 x 10/100/1000BASE-T 802.3bt (90W) ports
Full / Half-Duplex (autosensing)
MACsec-capable
2 x Stacking/QSFP28 ports* (unpopulated)
1 x Serial console port (RJ-45)
1 x 10/100/1000BASE-T out-of-band management port
2 x USB A ports for management or external USB flash
1 x USB Micro-B console port
1 x VIM slot
PoEYes
PoE Ports24 x PoE
PoE Power Budget1x715W: 494W
2x715W: 1079W
1x1100W: 879W
1 x 2000W @ 100-120VAC: 879W
1 x 2000W @ 200-240VAC: 1779W
2 x 2000W @ 100-120VAC: 1869W
2 x 2000W @ 200-240VAC: 2160 W
Max Power Consumption2480W
DimensionsChassis Only:
Height: 44 mm (1.73 in.)
Width: 441 mm (17.36 in.)
Depth: 442 mm (17.42 in.)
With PSU
Height: 44 mm (1.73 in.)
Width: 441 mm (17.36 in.)
Depth: 449 mm (17.68 in.)
Weight6.25 kg (13.78 lb.)
Shipping weight9.98 kg
Package size590 × 552 × 155 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What is the PoE power budget per port when all 24 ports are active under sustained load?

Each port delivers up to 90 W; the total budget depends on the installed power supplies — one 715 W supply gives 494 W, two 715 W supplies give 1079 W, one 1100 W supply gives 879 W, one 2000 W supply gives 879 W at 100-120 VAC or 1779 W at 200-240 VAC, two 2000 W supplies give 1869 W at 100-120 VAC or 2160 W at 200-240 VAC.

What are the typical heat and noise levels when the 5520-24W runs continuously with a full 2480 W power draw?

The chassis measures 44 mm high, 441 mm wide and 449 mm deep with PSUs installed and weighs 6.25 kg; fan speed and acoustic output scale with internal temperature and total power consumption up to 2480 W.

Which power supplies and uplink modules must I already own to operate the 24-port 90 W PoE switch?

The unit ships with unpopulated PSU bays and two empty QSFP28 stacking ports; you need at least one supported power supply (715 W, 1100 W or 2000 W) and QSFP28 transceivers or DAC cables for uplinks or stacking.
