Silver 1U rackmount switch, 24 SFP+ ports, two QSFP28 ports, front console and management ports

Extreme Networks

Extreme Networks 5520-24X 24-port SFP+ network switch

SKU CH-7ECH-2VSR8 MPN 5520-24X

Managed 24-port SFP+ switch with 10 GbE ports and two QSFP28 stacking links

  • Network Management TypeManaged
  • Management Interface24 x 100M/1G/10GBASE-X (SFP+) ports** (unpopulated) 2 x Stac
  • Max Power Consumption171W
  • DimensionsChassis Only Height: 44 mm (1.73 in.) Width: 441 mm (17.36 i
  • Weight6.25 kg (13.78 lb.)

Model 5520-24X

Struck-through versions exist but are not stocked here.

  • 24 SFP+ ports deliver 10Gb connectivity for high-density edge deployments
  • 2 QSFP28 stacking ports enable 25Gb uplinks and resilient switch stacking
  • Managed by Extreme Platform ONE or cloud IQ for unified network control
  • Universal Hardware runs dual-persona OS for flexible deployment choices
  • 171W max power draw in a 1U chassis for efficient rack density

Edge switch for 10Gb SFP+ uplinks

The Extreme Networks 5520-24X is a managed aggregation switch with 24 unpopulated SFP+ ports running at 100M, 1G or 10G speeds. Two QSFP28 stacking ports and a dedicated RJ-45 management port complete the front panel. It fits a standard 1U rack space and draws up to 171W.

Suited for fibre-heavy wiring closets.

Network teams needing dense 10Gb fibre uplinks from access switches or servers will use every port. Sites that require RJ-45 PoE for phones, cameras or Wi-Fi APs cannot connect those devices directly because no copper ports are present. Buyers wanting pre-installed transceivers must source them separately.

24 SFP+ ports decide the fit

The defining specification is the count of 24 SFP+ interfaces that accept 100M, 1G or 10G modules. If the design calls for fewer fibre ports or for integrated RJ-45 connectivity, a different model is required.

Highlights

  • 24 SFP+ ports deliver 10Gb connectivity for high-density edge deployments
  • 2 QSFP28 stacking ports enable 25Gb uplinks and resilient switch stacking
  • Managed by Extreme Platform ONE or cloud IQ for unified network control
  • Universal Hardware runs dual-persona OS for flexible deployment choices
  • 171W max power draw in a 1U chassis for efficient rack density

Specifications

BrandExtreme Networks
Series5520 Series
Model5520-24X
Part Number5520-24X
Network Management TypeManaged
Management Interface24 x 100M/1G/10GBASE-X (SFP+) ports** (unpopulated)
2 x Stacking/QSFP28 ports* (unpopulated)
1 x Serial console port (RJ-45)
1 x 10/100/1000BASE-T out-of-band management port
2 x USB A ports for management or external USB flash
1 x USB Micro-B console port
1 x VIM slot
Max Power Consumption171W
DimensionsChassis Only
Height: 44 mm (1.73 in.)
Width: 441 mm (17.36 in.)
Depth: 442 mm (17.42 in.)
With PSU
Height: 44 mm (1.73 in.)
Width: 441 mm (17.36 in.)
Depth: 449 mm (17.68 in.)
Weight6.25 kg (13.78 lb.)
Shipping weight6.26 kg
Package size597 × 551 × 165 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What does the SFP+ interface cap the 24 ports at in practice?

Each SFP+ port runs at 100 Mb, 1 Gb or 10 Gb depending on the transceiver you fit, so the practical ceiling is 10 Gbps per port.

What rack depth and weight must the cabinet accommodate?

The chassis is 442 mm deep and weighs 6.25 kg; with the power supply fitted the depth grows to 449 mm.

How do you initially configure the switch, and what step is often missed?

Connect to the RJ-45 serial console port, run the first-time setup wizard, then save the running configuration — many forget the final save and lose settings after a reboot.
