Silver 1U rackmount server chassis with four front hot-swap drive bays

ASUS

ASUS RS300-E11-WOCPU011Z barebone server 1U rackmount LGA 1200 DDR4 128GB 4×3.5" hot-swap 450W redundant

SKU CH-5DTT-PAC42 MPN RS300-E11-WOCPU011Z

1U rackmount barebone with four hot-swap 3.5" bays, dual 450W 80+ Platinum redundant power, LGA 1200 socket for Xeon E-2300, and DDR4 UDIMM support up to 128GB

  • Form Factor1U Rackmount
  • WorkloadGeneral Purpose Server
  • CPU TypeIntel Xeon
  • CPU SocketLGA 1200
  • Installed CPUNo CPU Installed
  • Max Processors1
  • Supports Intel Xeon E-2300 processors up to 95W TDP
  • 128GB maximum DDR4 memory across four 288-pin slots
  • Four 3.5-inch hot-swap drive bays with 6 SATA 600 ports
  • PCIe 4.0 x16 and x8 expansion slots for add-in cards
  • Dual Intel I210-AT Gigabit LAN plus dedicated management port

Form factor and target workload

The ASUS RS300-E11-WOCPU011Z is a 1U rackmount barebone server designed for general purpose workloads. It arrives without a CPU or memory installed, allowing integrators to select components that match their specific performance and budget requirements.

Who this suits and who should look elsewhere

System builders who need a compact chassis with four hot-swap 3.5-inch drive bays and redundant power will find the platform a direct fit. Buyers who require more than one processor socket, additional expansion slots beyond the three provided, or integrated graphics beyond a single HDMI output should consider a different form factor.

Deciding specification

The Intel C252 chipset and LGA 1200 socket limit the system to a single Xeon E-2300 processor with a 95W thermal envelope, dual-channel DDR4 3200/2933/2666 UDIMM memory up to 128GB, and PCI Express 4.0 lanes on the primary slots.

Highlights

  • Supports Intel Xeon E-2300 processors up to 95W TDP
  • 128GB maximum DDR4 memory across four 288-pin slots
  • Four 3.5-inch hot-swap drive bays with 6 SATA 600 ports
  • PCIe 4.0 x16 and x8 expansion slots for add-in cards
  • Dual Intel I210-AT Gigabit LAN plus dedicated management port

Specifications

BrandASUS
ModelRS300-E11-WOCPU011Z
Form Factor1U Rackmount
WorkloadGeneral Purpose Server
CPU TypeIntel Xeon
CPU SocketLGA 1200
Installed CPUNo CPU Installed
Max Processors1
North BridgeIntel C252
Memory Slots4 x 288Pin
Installed Memory SizeNo Memory Installed
Max Memory SupportedMaximum up to 128GB UDIMM
Memory Type SupportedDDR4 3200/2933/2666 UDIMM
Channel SupportedDual Channel
Installed HDDNo Storage Installed
Serial ATA6 x SATA 600
PCI ExpressTotal PCI/PCI-X/PCI-E/PIKE Slots: 3
1 x PCI-E x 16 (Gen4 x16 Link, switch to x8 link when slot B occupied), FH/HL
1 x PCI-E x 8 (Gen4 x8 Link), HH/HL*
1 x PCI-E x 4 (Gen3 x4 Link), Proprietary R/A slot
* not available when supporting NVME SSD
First LANIntel I210-AT
Max. LAN Speed1 Gigabit
3.5" Bays4
Front USB2 x USB 3.2 Gen1
COM1
Rear USB2 x USB 3.2 Gen 2
RJ452
Other Ports1 x HDMI port from CPU
Max. Power450W Redundant 80 Plus
TemperatureOperating temperature: 10°C ~ 35°C
Non operating temperature: -40°C ~ 70°C
HumidityNon operating humidity: 20% ~ 90% ( Non condensing)
Dimensions19.57" x 17.3" x 1.73"
Weight33.51 lbs.
Shipping weight15.88 kg
Package size826 × 584 × 178 mm

Questions about this item

What rack depth and clearance does the 1U chassis with 19.56" × 17.30" dimensions need?

The server is 19.56 inches deep and 17.30 inches wide, so the rack must provide at least that depth plus cable bend radius at the rear and front door clearance for the hot-swap drive carriers.

Which PCIe slot should be populated first when adding a full-height GPU and a RAID controller?

Install the GPU in the PCIe 4.0 x16 full-height slot; if the x8 half-height slot is also used, the x16 link drops to x8, so plan card placement before tightening the riser screws.

How often should the dual 450W 80+ Platinum power supplies and hot-swap backplane be checked?

Inspect both PSU status LEDs and listen for fan-speed changes during each scheduled maintenance window; the backplane has no moving parts but verify drive-carrier latch springs annually.
