ASRock Rack 2U24E2S-ROME 2U barebone server 24 NVMe bays 2 SATA/SAS bays 16 DDR4 slots
A 2U rackmount storage barebone accepting one AMD EPYC 7003 or 7002 processor, 16 DDR4 3200 modules, 24 front NVMe bays, two rear SATA/SAS bays, and two M.2 slots
- Form Factor2U Rackmount
- WorkloadStorage Server
- CPU TypeSupports AMD EPYC 7003 (with AMD 3D V-Cache Technology*)/700
- CPU SocketSocket SP3
- Installed CPUNo CPU Installed
- Max Processors1
- 24 NVMe hot-swap bays deliver massive all-flash capacity
- 2 rear SATA/SAS bays add flexible boot or backup storage
- 16 DDR4-3200 DIMM slots enable large memory configurations
- 1+1 1200 W redundant PSU keeps the system running during a power-supply failure
- Dual 1 GbE Intel i350 plus dedicated IPMI simplifies remote management
2U rackmount storage barebone
The ASRock Rack 2U24E2S-ROME is a 2U rackmount barebone designed for storage-heavy workloads. It targets system integrators and IT teams building dense NVMe arrays around a single AMD EPYC 7002 or 7003 series processor. No CPU or memory is installed, so the buyer supplies both.
Sustained load with 24 NVMe bays
A passive 24-port backplane connects every front 2.5-inch bay directly to the CPU PCIe 4.0 lanes, giving each drive a full x4 link without oversubscription. Two rear 2.5-inch bays add SATA or SAS capacity through an optional HBA or RAID card. The single low-profile PCIe 4.0 x8 slot remains free for that adapter or a NIC.
Redundant power and IPMI access
Dual 1200W redundant power supplies keep the chassis running through a unit failure. The Aspeed AST2500 BMC provides a dedicated IPMI port for out-of-band management. Dual Intel i350 1GbE ports handle data traffic, while front USB 3.2 Gen1 ports allow quick local access. Sixteen 288-pin DDR4 3200 slots support RDIMM, LRDIMM and 3DS modules up to the platform limit.
Highlights
- 24 NVMe hot-swap bays deliver massive all-flash capacity
- 2 rear SATA/SAS bays add flexible boot or backup storage
- 16 DDR4-3200 DIMM slots enable large memory configurations
- 1+1 1200 W redundant PSU keeps the system running during a power-supply failure
- Dual 1 GbE Intel i350 plus dedicated IPMI simplifies remote management
Specifications
| Brand | ASRock Rack |
|---|---|
| Model | 2U24E2S-ROME |
| Form Factor | 2U Rackmount |
| Workload | Storage Server |
| CPU Type | Supports AMD EPYC 7003 (with AMD 3D V-Cache Technology*)/7002 Series Processors *A BIOS update is required to support AMD EPYC 7003 series processors with AMD 3D V-Cache Technology |
| CPU Socket | Socket SP3 |
| Installed CPU | No CPU Installed |
| Max Processors | 1 |
| Memory Slots | 16 x 288Pin |
| Installed Memory Size | No Memory Installed |
| Memory Type Supported | DDR4 3200 |
| Installed HDD | No Storage Installed |
| M.2 | 2 M.2 (PCIe4.0 x4/SATA) supports 22110/2280 form factor |
| GPU/VPU | Aspeed AST2500 |
| Video Memory | 256MB DDR4 |
| PCI Express | 1 low-profile PCIe4.0 x8 |
| First LAN | Intel i350-AM2 |
| Max. LAN Speed | 1 Gigabit |
| Hot-Swap Bays | Front Side Drive Bay: 24 Hot-swap 2.5" drive bays, Supports 24 NVMe (PCIe x4) drives Front Side Backplane: one 24-port NVMe/SAS/SATA passive backplane Rear Side: 2 Hot-swap 2.5" drive bays, supports 2 SAS/SATA Drives with optional HBA/RAID adapter card Rear Side Bakplane: one 2-port SAS/SATA passive backplane |
| Front USB | 2 x USB 3.2 Gen1 |
| COM | 1 |
| VGA | 1 |
| Rear USB | 2 x USB 3.2 Gen1 |
| RJ45 | 2 RJ45 (1GbE) by Intel i350-AM2 1 dedicated IPMI LAN |
| Max. Power | Type: 1+1 CRPS Output Watts: 1200W Efficiency: 80-PLUS Platinum AC Input: Lowline: 100-127V, Highline: 200-240V |
| Temperature | Operation temperature: 10°C ~ 35°C Non operation temperature: -40°C ~ 70°C |
| Humidity | Non operation humidity: 20% ~ 90% ( Non condensing) |
| Dimensions | 25.98" x 17.24" x 3.44" |
| Shipping weight | 26.31 kg |
| Package size | 1003 × 622 × 286 mm |
Questions about this item
How loud is the 1+1 1200W redundant PSU setup when the 2U chassis runs 24 NVMe drives all day?
The 2U24E2S-ROME ships with 1+1 1200W redundant power supplies; fan speed scales with load and inlet temperature, so sustained 24-drive operation will run the fans higher than idle but within server-typical acoustic limits for a 2U rackmount.
Which AMD EPYC processor and DDR4 memory must I supply before the barebone will POST?
You need one Socket SP3 AMD EPYC 7002 or 7003 series CPU (7003 3D V-Cache parts require a BIOS update) plus DDR4 3200 RDIMM or LRDIMM modules to populate the 16 x 288-pin slots.
Can I keep my existing 2.5-inch SATA SSDs and use the rear bays while the front handles NVMe?
Yes, the rear provides 2 hot-swap 2.5-inch bays for SAS or SATA drives with an optional HBA or RAID adapter, while the front backplane runs 24 NVMe PCIe 4.0 x4 bays simultaneously.
