Silver 1U rackmount barebone server with front drive bays

ASRock Rack

ASRock Rack 1U4LW-X470 RPSU 1U barebone server

SKU CH-EB62-TXZ57 MPN 1U4LW-X470 RPSU

1U rackmount barebone with redundant 300 W power supply, AM4 socket for Ryzen CPUs, four DDR4 ECC UDIMM slots up to 128 GB, six SATA 600 ports, dual Gigabit LAN and IPMI via Aspeed AST2500

  • Form Factor1U Rackmount
  • WorkloadGeneral Purpose Server
  • CPU TypeSupports AMD Ryzen PRO 3000 / 2000 Series Processors Support
  • CPU SocketAM4
  • Installed CPUNo CPU Installed
  • Max Processors1
  • 1U rackmount with 300W redundant power supply for space-efficient deployment
  • Supports AMD Ryzen AM4 processors including PRO 3000 and 2000 series
  • Four DDR4 ECC UDIMM slots up to 128GB for reliable memory capacity
  • Six SATA 600 ports plus two M.2 slots supporting SATA3 and PCIe 3.0 x2
  • Dual Intel I210 Gigabit LAN with ASPEED AST2500 BMC for remote management

1U Rackmount AM4 Barebone Server

This new ASRock Rack barebone ships as a 1U rackmount chassis with a 300 W redundant power supply. It is built around the AMD X470 chipset and accepts a single AM4-socket Ryzen processor from the 3000, 2000 or first-generation families. No CPU or memory comes installed, so the integrator chooses both.

For single-socket general-purpose builds

The board suits integrators who need a compact server that can run ECC DDR4 UDIMMs up to 128 GB across four slots. It is not suited for workloads that require dual processors, registered DIMMs, or more than two M.2 devices. Builds needing ten-gigabit networking or additional PCIe x16 slots should look elsewhere.

Dual-channel ECC DDR4 to 128 GB

Four 288-pin slots support DDR4 at 3200, 2933, 2666, 2400 or 2133 MHz in dual-channel mode with ECC or non-ECC UDIMMs. This memory ceiling and ECC support are the decisive factors when matching the platform to reliability-focused workloads.

Highlights

  • 1U rackmount with 300W redundant power supply for space-efficient deployment
  • Supports AMD Ryzen AM4 processors including PRO 3000 and 2000 series
  • Four DDR4 ECC UDIMM slots up to 128GB for reliable memory capacity
  • Six SATA 600 ports plus two M.2 slots supporting SATA3 and PCIe 3.0 x2
  • Dual Intel I210 Gigabit LAN with ASPEED AST2500 BMC for remote management

Specifications

BrandASRock Rack
Model1U4LW-X470 RPSU
Form Factor1U Rackmount
WorkloadGeneral Purpose Server
CPU TypeSupports AMD Ryzen PRO 3000 / 2000 Series Processors
Supports AMD Ryzen 3rd / 2nd Gen Processors
Supports AMD Ryzen 2nd / 1st Gen Processors with Radeon Vega Graphics
CPU SocketAM4
Installed CPUNo CPU Installed
Max Processors1
North BridgeAMD X470
Memory Slots4 x 288Pin
Installed Memory SizeNo Memory Installed
Max Memory Supported128GB
Memory Type SupportedDDR4 3200/2933/2666/2400/2133 MHz ECC/UDIMM
Channel SupportedDual Channel
ECC SupportedYes
Serial ATA6 x SATA 600
SATA RAIDRAID 0/1/10
M.22 (2242/2260/2280/22110, supports SATA3 and PCIe 3.0 x2 or supports PCIe 2.0 x4 only)
GPU/VPUAspeed AST2500
Video Memory16 MB DDR4
PCI ExpressSLOT6: PCIe3.0 x16 (splittable in x4/4/4/4); auto switch to x8 when SLOT4 is occupied
SLOT5: PCIe3.0 x4
SLOT4: PCIe x16 (PCIe3.0 x8)
First LANIntel I210-AT
Max. LAN Speed1 Gigabit
Front USB2 x USB 3.0
COM1
VGA1
Rear USB2 x USB 3.2 Gen1
RJ452 x RJ45 GLAN by Intel i210AT
1 x RJ45 Dedicated IPMI LAN port
Max. Power300W
Dimensions1.75" x 21.00" x 19.00"
Shipping weight16.85 kg
Package size794 × 641 × 229 mm

Questions about this item

Which AMD Ryzen processor generations can I install in the AM4 socket?

The AM4 socket accepts AMD Ryzen PRO 3000 and 2000 Series, Ryzen 3rd and 2nd Gen, plus Ryzen 2nd and 1st Gen with Radeon Vega Graphics.

Will my existing DDR4 ECC UDIMM modules work in the four 288-pin slots?

Yes, the board supports DDR4 3200, 2933, 2666, 2400 and 2133 MHz ECC and non-ECC UDIMM up to 128 GB in dual-channel mode.

How can I verify the IPMI interface is functioning after assembly?

Connect the dedicated Realtek RTL8211E GLAN port; the ASPEED AST2500 BMC with 16 MB video memory will present a web management console at its DHCP address.
