Silver 1U rackmount barebone server with front drive bays and dual 10GbE ports

ASRock Rack

ASRock Rack 1U2-X570/2T 1U barebone server

SKU CH-AEQ1-XG758 MPN 1U2-X570/2T

1U rackmount barebone with AMD X570 chipset, dual 10GbE LAN, IPMI remote management and support for Ryzen 5000 CPUs

  • Form Factor1U Rackmount
  • WorkloadEdge Server
  • CPU TypeSupports AMD Ryzen 5000 Series Desktop Processors Supports A
  • CPU SocketAM4
  • Installed CPUNo CPU Installed
  • Max Processors1
  • 1U rackmount edge server with 265W PSU fits dense deployments
  • AMD X570 chipset supports Ryzen 5000 and 3000 desktop processors
  • Four DDR4 288-pin slots accept up to 128GB ECC memory
  • M.2 2280 slot runs PCIe 4.0 x4 or SATA 6Gb/s
  • Dual 10GbE RJ45 and IPMI remote management built in

Compact 1U edge server barebone

The ASRock Rack 1U2-X570/2T is a 1U rackmount barebone designed for edge workloads. It ships with a 265W power supply and an AMD X570 chipset that accepts AM4 desktop processors. The platform uses an ASPEED AST2500 controller with 16MB video memory for basic display output and IPMI remote management. Dual 10GbE RJ45 ports are provided on-board.

Suits single-socket edge deployments

This chassis fits builders who need a short-depth 1U box with front I/O and space for two 3.5-inch drives plus two 2.5-inch 7mm drives. Buyers who require more than one processor socket, additional PCIe expansion slots, or a higher-wattage power supply should look at larger form factors.

CPU support decides compatibility

The board supports AMD Ryzen 5000 Series, 4000 G-Series, PRO 4000 and 3000 Series, and 3rd Gen desktop processors in the AM4 socket. Only processors with PRO technologies enable ECC on the four 288-pin DDR4 2933 slots, which accept up to 32GB per module for a 128GB maximum. A single M.2 2280 slot provides PCIe 4.0 x4 or SATA storage.

Highlights

  • 1U rackmount edge server with 265W PSU fits dense deployments
  • AMD X570 chipset supports Ryzen 5000 and 3000 desktop processors
  • Four DDR4 288-pin slots accept up to 128GB ECC memory
  • M.2 2280 slot runs PCIe 4.0 x4 or SATA 6Gb/s
  • Dual 10GbE RJ45 and IPMI remote management built in

Specifications

BrandASRock Rack
Model1U2LW-X570/2L2T
Form Factor1U Rackmount
WorkloadEdge Server
CPU TypeSupports AMD Ryzen 5000 Series Desktop Processors
Supports AMD Ryzen 4000 G-Series Desktop Processors with Radeon Graphics
Supports AMD Ryzen PRO 4000 and 3000 Series Desktop Processors
Supports 3rd Gen AMD Ryzen Desktop Processors
Supports AMD Ryzen 3000 Series Processors with Radeon Graphics
CPU SocketAM4
Installed CPUNo CPU Installed
Max Processors1
North BridgeAMD X570
Memory Slots4 x 288Pin
Installed Memory SizeNo Memory Installed
Max Memory Supported128GB
Memory Type SupportedDDR4 2933
ECC SupportedECC support is only with Processors with PRO technologies
Installed HDDNo Storage Installed
M.21 M-key (PCIe4.0* x4 or SATA 6Gb/s); Form factor: 2280
*Supports PCIe3.0 when using AMD Ryzen 3000 Series Processors with Radeon Graphics
GPU/VPUAspeed AST2500
Video Memory16MB DDR4
Max. LAN Speed1 Gigabit
3.5" BaysSupports 2 fixed 3.5" drives and 2 fixed 2.5" 7mm drives
Front USB2 x Type-A (USB 3.2 Gen1)
VGA1
Rear USB2 x USB 3.2 Gen1 Type-A
RJ452
Max. Power265W 80-Plus Bronze
Dimensions1.71" x 16.93" x 9.84"
Shipping weight9.78 kg
Package size622 × 572 × 216 mm

Questions about this item

What CPU socket and cooler clearance does the 1U2-X570/2T need?

The board uses an AM4 socket in a 1U rackmount chassis; choose a low-profile AM4 cooler rated for 1U height and verify the 265 W PSU can handle your processor TDP.

Which memory modules install correctly and which slot order is the common mistake?

Install DDR4-2933 SO-DIMMs in the four 288-pin slots; ECC works only with Ryzen PRO CPUs, and the frequent error is mixing ECC and non-ECC DIMMs in the same system.

What drive bays and M.2 slot will need attention later?

Two fixed 3.5" bays and two fixed 2.5" 7 mm bays plus one M.2 2280 M-key slot; the M.2 runs at PCIe 4.0 x4 with Ryzen 5000 but drops to PCIe 3.0 with Ryzen 3000.
