Black 120 mm square case fan 32 mm thick with two-wire power lead

Zyvpee

Zyvpee BFB1224HH 120mm 32mm 24V 2-pin case fan

SKU CH-MF9W-J738N

A 24 V, 120 mm case fan with 2‑ball bearings moves 54 CFM at 2800 RPM and 35 dBA

  • TypeCase Fan
  • Bearing Type2 Ball
  • Power Connector2 Pin
  • ColorBlack
  • LEDNon-LED
  • Dimensions120*32mm
  • 2-ball bearing extends service life
  • 2800 RPM delivers 54.00 CFM airflow
  • 35 dBA noise level suits quiet builds
  • 120 mm x 32 mm frame fits standard mounts
  • 24 V 0.8 A 2-pin power for server use

120 mm 24 V server fan

The Zyvpee BFB1224HH is a 120 mm square frame fan that is 32 mm thick and runs on 24 V DC power. It uses a two-ball bearing and a simple two-pin connector with no LED lighting. This unit suits servers or industrial chassis that require a 24 V supply.

2800 RPM at 54 CFM

At 2800 RPM the fan moves 54.00 CFM of air while producing 35 dBA of noise. The 0.8 A current draw at 24 V defines whether your power source can sustain the load. Verify that your system provides a 24 V header before ordering.

Two-pin plug installs in seconds

The two-pin connector plugs directly onto a matching 24 V header; no PWM signal wire is present so speed control is not possible. Builders who need variable speed or a three-pin tachometer should choose a different model. Ensure the 120 mm mounting holes align with your chassis.

Highlights

  • 2-ball bearing extends service life
  • 2800 RPM delivers 54.00 CFM airflow
  • 35 dBA noise level suits quiet builds
  • 120 mm x 32 mm frame fits standard mounts
  • 24 V 0.8 A 2-pin power for server use

Specifications

Brand3ccooler.com
SeriesBFB1224HH -5A45
ModelBFB1224HH
TypeCase Fan
Bearing Type2 Ball
Power Connector2 Pin
ColorBlack
LEDNon-LED
Dimensions120*32mm

Questions about this item

What airflow and noise should I expect from the 2800 RPM rating once the fan is installed?

The fan delivers 54.00 CFM at 35 dBA when running at its rated 2800 RPM.

How does the 2-pin power connector limit speed control options?

The 2-pin connector supplies constant 24 V power, so the fan runs at full speed without PWM or voltage regulation.

Will the 120 mm by 32 mm frame fit standard 120 mm mounting holes in my case?

Yes, the 120 mm square frame with 32 mm thickness matches common 120 mm fan mounting patterns.
