Black metal 160mm axial fan with four wires IP44

Zyvpee

Zyvpee A2D160-AB22-06 160mm 3 Phase 400Vac IP44 case fan

SKU CH-RATE-6097G

Three-phase 400 V AC axial fan, 160 mm, IP44 rated, dual ball bearings, 2500-2999 RPM

  • Typeac axial fan
  • Fan Size170mm
  • Bearing Type2 Ball
  • RPM2500-2999 RPM
  • Power Connector4 Wires
  • ColorBlack
  • Three-phase 400 V AC power for industrial-grade airflow
  • IP44-rated enclosure resists dust and water splashes
  • Class F insulation tolerates high operating temperatures
  • Dual ball bearings extend service life under continuous duty
  • Four-wire connector enables speed monitoring and control

Industrial AC axial fan for 400 V three-phase

The Zyvpee A2D160-AB22-06 is a 160 mm AC axial fan built for three-phase 400 Vac supplies at 50 or 60 Hz. It draws 0.13 A at 50 Hz and 0.14 A at 60 Hz, making it suited to industrial enclosures and rack cabinets that run on standard three-phase mains. The fan is supplied new in black metal housing.

IP44 rating and four-wire connection for protected

Rated IP44 and insulation Class F, the unit resists splashing water and solid particles larger than 1 mm, so it can be mounted in filtered or semi-exposed positions. A four-wire lead simplifies wiring to three-phase terminal blocks or motor starters. Dual ball bearings support the 2500 to 2999 RPM speed range with reduced wear in continuous duty.

Direct replacement for M2D068-BC series fans

This model matches the M2D068-BC series form factor, allowing a like-for-like swap in existing cut-outs without re-drilling. The upgrade is worth it when the original fan has reached end of life or when a new build needs a verified 160 mm three-phase source. Buyers who need a single-phase or low-voltage fan should select a different product.

Highlights

  • Three-phase 400 V AC power for industrial-grade airflow
  • IP44-rated enclosure resists dust and water splashes
  • Class F insulation tolerates high operating temperatures
  • Dual ball bearings extend service life under continuous duty
  • Four-wire connector enables speed monitoring and control

Specifications

SeriesM2D068-BC
ModelA2D160-AB22-06
Typeac axial fan
Fan Size170mm
Bearing Type2 Ball
RPM2500-2999 RPM
Power Connector4 Wires
ColorBlack
LEDNon-LED
FeaturesAC Axial Fan
Dimensions160mm

Questions about this item

What does the 3-phase 400 Vac rating mean for the power connection?

It requires a three-phase 400 Vac supply at 50/60 Hz drawing 0.13/0.14 A; a standard single-phase mains or PC power connector cannot drive it.

What are the exact mounting dimensions for the 160 mm metal frame?

The fan body measures 170 mm overall with a 160 mm mounting pattern; verify your chassis has matching screw holes and clearance for the metal housing.

How is the four-wire lead connected for three-phase operation?

Three wires carry the 400 Vac phases and the fourth is typically a protective earth; wire them to a suitable three-phase contactor or drive — do not connect to a single-phase source.
