White rectangular biometric terminal with 3.5-inch color touchscreen, fingerprint sensor and numeric keypad

ZKTECO

ZKTECO iClock660 Fingerprint Time Attendance Terminal Door Access Control

SKU CH-8VE2-XYTA9

Fingerprint time-attendance terminal with door-access control, 8,000 fingerprint capacity and 100,000 records on a 3.5-inch colour screen

Options: Select iClock660 Standard

  • Handles 10,000 employees with 8,000 fingerprint templates
  • Stores 100,000 attendance records for long-term audits
  • 5-inch colour screen gives clear on-device feedback
  • TCP/IP and U-disk options simplify data collection
  • Runs 0–45 °C at 20–80 % humidity

ZKTECO iClock660 Fingerprint Terminal

The ZKTECO iClock660 is a fingerprint time attendance terminal with integrated door access control for corporate environments. It supports up to 10000 users and stores 8000 fingerprint templates alongside 100000 transaction records. A 3.5 inch HD TFT colour screen provides a full graphical interface for intuitive operation. The unit runs on a built-in Linux system using the ZKFinger 10.0 dual-engine algorithm for high-speed recognition.

TCP/IP and U-Disk Communication Limits

Network connectivity relies on TCP/IP for real-time data transfer between multiple terminals and management software. An RS232 and RS485 interface are also available for alternative wiring schemes. A U-disk port allows offline uploading and downloading of attendance data when a network link is not practical. The terminal operates reliably between 0 and 45 degrees Celsius at 20 to 80 percent humidity. Power is supplied via a DC 12V 3A adapter.

Wall Mount Installation and Common Issues

The compact chassis measures 214 by 150 by 44 millimetres and is designed for direct wall mounting using the supplied backplate. Wiring for the lock, exit button and door sensor connects to clearly labelled terminals on the rear. Most installation problems arise from incorrect cable polarity on the 12V supply or loose RS485 connections that cause communication dropouts. Enrolling the full 8000 fingerprints on the device keypad using T9 input can be time consuming for large deployments.

Highlights

  • Handles 10,000 employees with 8,000 fingerprint templates
  • Stores 100,000 attendance records for long-term audits
  • 5-inch colour screen gives clear on-device feedback
  • TCP/IP and U-disk options simplify data collection
  • Runs 0–45 °C at 20–80 % humidity

Specifications

No published specifications for this item yet.

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I pick a terminal with 8,000 fingerprint capacity or one with 10,000 user capacity for my office?

This model provides both figures together — 8,000 fingerprint templates and 10,000 total users — so you do not choose between them; the single device supports up to 10,000 enrolled people with fingerprints for 8,000 of them.

What does the 100,000 record capacity mean for daily use?

It stores up to 100,000 attendance or access events before the oldest logs are overwritten, giving months of history for a typical workforce before you need to offload data via TCP/IP or U-disk.

How does the TCP/IP and RS485 interface limit real-world deployment?

TCP/IP connects the unit to your LAN for central software management, while RS485 allows multi-device wiring over longer cable runs; both are built in, so you can mix networked and daisy-chained installations without extra adapters.
