Small black box with HDMI ports and optical plus 3.5mm audio outputs

WRIARICH

WRIARICH HDMI ARC Audio Extractor Converter 4K@60Hz

SKU CH-9H6V-KKDJD

Extracts audio from an HDMI signal to optical and 3.5 mm outputs while passing 4K video at 60 Hz with ARC support

  • TypeAudio Signal Converters
  • Changer TypeHDMI
  • StyleYPbPr to HDMI Converter
  • ColorBlack
  • SpecificationsHDMI, Auxiliary, 5, 2.28 L x 2.13 W x 0.1 H inches, 0.15 kil
  • Connector B1x USB 2.0 female
  • Extract audio to soundbar via optical or 3.5mm jack
  • Switch between stereo pass-through 2CH and 5.1CH surround modes
  • Pass 4K video at 60Hz with HDCP 2.2 compliance
  • Use ARC to return TV audio to external speakers
  • Connect consoles, streamers, PCs and Blu-ray players

What This Extractor Does

The WRIARICH HDMI ARC Audio Extractor Converter takes one HDMI source and provides an HDMI video pass-through plus separate optical Toslink SPDIF and 3.5 mm analogue stereo outputs. It is built for owners of soundbars, AV receivers or headphones who need to pull audio from a 4K@60 Hz source such as a games console, streaming stick or Blu-ray player without relying on a TV's own audio outputs.

Build and Daily Connections

A compact black enclosure measuring 2.28 L x 2.13 W x 0.1 H inches and weighing .15 kilograms sits inline between source and display using standard HDMI cables. The front panel offers a three-position switch for Pass, 2CH and 5.1CH audio modes, while the rear adds a USB 2.0 female port for optional power. Optical and 3.5 mm jacks sit side by side so you can feed a soundbar and headphones simultaneously when the source is set to PCM stereo.

The Spec That Decides Fit

Maximum supported video is 4K at 60 Hz with HDCP 2.2 and deep-colour bit depths of 24, 30 and 36 bits. The optical output carries 5.1-channel Dolby Digital, Dolby TrueHD and DTS-HD, but the device does not handle Dolby Digital Plus or CEC commands. If your source only outputs Dolby Digital Plus or you require CEC control for volume, this extractor will not pass that audio format.

Highlights

  • Extract audio to soundbar via optical or 3.5mm jack
  • Switch between stereo pass-through 2CH and 5.1CH surround modes
  • Pass 4K video at 60Hz with HDCP 2.2 compliance
  • Use ARC to return TV audio to external speakers
  • Connect consoles, streamers, PCs and Blu-ray players

Specifications

BrandMediasonic
Series4K@60Hz ARC
Model4K@60Hz ARC
Part NumberTechole HDMI
TypeAudio Signal Converters
Changer TypeHDMI
StyleYPbPr to HDMI Converter
ColorBlack
SpecificationsHDMI, Auxiliary, 5, 2.28 L x 2.13 W x 0.1 H inches, 0.15 kilograms, Black, 4K@60Hz ARC, Techole HDMI, 1 Year Manufacturer, avedio links
Connector B1x USB 2.0 female
Connector StyleMale
FeaturesHDMI
Dimensions14.33in W x 12.83in H x 9.06in D
Weight0.15 kilograms
Package Quantity1
Package Contents1 x 4K@60Hz ARC

Questions about this item

What HDMI version does the 4K@60Hz ARC support, and what resolution ceiling does that impose?

The extractor works up to HDMI 2.0 with HDCP 2.2, so 4K at 60 Hz is the highest guaranteed video mode.

What are the physical dimensions and weight of the 4K@60Hz ARC unit?

It measures 2.28 by 2.13 by 0.1 inches and weighs 0.15 kilograms.

How do I set the audio mode switch on the 4K@60Hz ARC for a soundbar that only accepts stereo PCM?

Slide the selector to 2CH; the source device must also be set to PCM or stereo output.
