Compact rectangular diagnostic interface, matte black plastic housing, USB cable attached

VXDIAG

VXDIAG VCX Nano GM GDS2 Tech2Win Diagnostic Tool

SKU CH-60EK-SCJV9

Diagnose GM vehicles from 2000 to 2020 with GDS2 and Tech2Win software via SAE-J2534 pass-thru

  • Size/Dimensions‎6.89 x 5.2 x 1.93 inches
  • TypeCode Scanners & Accessories
  • Features‎Support PC-based diagnostics with rollout of the Global Dia
  • Diagnose GM vehicles from 2000 to 2020 with full system coverage
  • Program ECUs and modules using GDS2 V2022.5 and Tech2Win 16.02.24
  • Connect via SAE-J2534 pass-thru supporting CAN, UART, KW2000, Class2, GM LAN protocols
  • Compact 6.89 x 5.2 x 1.93 inch interface installs with VX Manager 1.8.4 driver
  • GDS2 software offers 10 languages while Tech2Win runs on 32-bit Windows 10 systems

Diagnostic Tool for GM and Opel Vehicles

The VXDIAG VCX Nano GM is a test and measurement device built for diagnosing engine, transmission, ABS and instrument panel faults. It also handles ECU, BCM and PCM programming and configuration tasks. Workshops and technicians working on Chevrolet, Cadillac, GMC, Buick, Hummer, Opel and Saab models from 2000 to 2020 will find it covers their core diagnostic needs. It does not support Holden vehicles.

Software Installation and Setup

Software is supplied as a free download rather than on a disc; GDS2, Tech2Win and the VX Manager 1.8.4 driver must be installed manually. The installer requires antivirus to be disabled and at least 4 GB of ROM available. Tech2Win runs only on a 32-bit operating system and will not install on Home edition Windows. Online technical support is available to assist with the process.

Protocol Coverage and Limitations

The interface complies with SAE-J2534-1 and SAE-J2534-2 pass-through standards and communicates over CAN, UART, KW2000, Class2 and GM LAN protocols. GDS2 provides Opel and Saab coverage while Tech2Win does not support those brands for the 2000 to 2010 period. The tool cannot address vehicles outside the listed makes and model years.

Highlights

  • Diagnose GM vehicles from 2000 to 2020 with full system coverage
  • Program ECUs and modules using GDS2 V2022.5 and Tech2Win 16.02.24
  • Connect via SAE-J2534 pass-thru supporting CAN, UART, KW2000, Class2, GM LAN protocols
  • Compact 6.89 x 5.2 x 1.93 inch interface installs with VX Manager 1.8.4 driver
  • GDS2 software offers 10 languages while Tech2Win runs on 32-bit Windows 10 systems

Specifications

BrandVXDIAG
ModelVXDIAG VCX NANO GM
Size/Dimensions‎6.89 x 5.2 x 1.93 inches
TypeCode Scanners & Accessories
Features‎Support PC-based diagnostics with rollout of the Global Diagnostic System GDS & GDS2

Questions about this item

How do I confirm the VXDIAG VCX Nano GM GDS2 Tech2Win is communicating with my vehicle after setup?

Connect the device via USB, open VX Manager 1.8.4 driver, and verify the interface shows a live connection; then launch GDS2 V2022 or Tech2Win 16.02.24 and run a quick vehicle identification to see live data from engine, transmission, ABS, or instrument panel modules.

What comes in the box with the VXDIAG VCX Nano GM and what must I obtain separately?

The package includes the VCX Nano GM hardware interface; software is not on a CD — you must download GDS2 V2022, Tech2Win 16.02.24, and VX Manager 1.8.4 driver from the supplier or request a USB stick, and you need a Windows PC with at least 4 GB RAM, 32-bit OS for Tech2Win, and antivirus disabled during installation.

Should I use GDS2 or Tech2Win for a 2010 Opel?

GDS2 supports Opel up to 2020; Tech2Win does not support Opel at all. For a 2010 Opel, choose GDS2 V2022.5 for diagnostics and programming.
