Green circuit board with a single USB-C port and two metal brackets

Vszerda

Vszerda USB 3.2 Gen2x2 Type-C PCIe 3.0 x4 Adapter

SKU CH-JN7D-3CJ9K

Adds a USB 3.2 Gen2x2 Type-C port running at 20Gbps via a PCIe 3.0 x4 slot, powered by SATA and using an ASMedia ASM3242 controller

  • Adds a 20 Gbps USB-C port via PCIe 3.0 x4
  • ASMedia ASM3242 controller ensures stable high-speed transfers
  • SATA 15-pin power delivers reliable energy to connected drives
  • Driver-free on Windows 10 and 11 for instant setup
  • Full-profile and low-profile brackets fit any chassis

USB 3.2 Gen2x2 Type-C PCIe Adapter

This Vszerda adapter adds a single USB 3.2 Gen2x2 Type-C port to a desktop through a PCIe 3.0 x4 slot. It uses an ASMedia ASM3242 controller and draws power from a SATA 15-pin connector. Both full-profile and low-profile brackets are supplied.

Suits builds needing one 20 Gbps Type-C port.

The card provides exactly one rear Type-C connection running at 20 Gbps, so it fits users who want to attach a single high-speed SSD or HDD. Builds that require several Type-C ports or internal headers should consider a different solution.

PCIe 3.0 x4 slot and SATA power required

Installation needs an available PCIe 3.0 x4 lane — compatible with x1, x4, x8 or x16 physical slots — and a free SATA 15-pin power lead from the PSU. Without both the card cannot operate.

Highlights

  • Adds a 20 Gbps USB-C port via PCIe 3.0 x4
  • ASMedia ASM3242 controller ensures stable high-speed transfers
  • SATA 15-pin power delivers reliable energy to connected drives
  • Driver-free on Windows 10 and 11 for instant setup
  • Full-profile and low-profile brackets fit any chassis

Specifications

No published specifications for this item yet.

Questions about this item

How do I verify the Type-C port is delivering 20Gbps after installing the ASM3242 card?

Connect a USB 3.2 Gen2x2 SSD to the rear Type-C port and run a sequential read/write test; speeds approaching 20Gbps confirm the link is operating at full PCIe 3.0 x4 width.

What comes in the box and what must I supply separately?

The package includes the PCIe adapter with ASM3242 controller plus full-profile and low-profile brackets; you must provide a free PCIe x1/x4/x8/x16 slot and a spare SATA 15-pin power connector from the PSU.

Which version should I choose if my motherboard only has PCIe 3.0 slots?

This single model is built for PCIe 3.0 x4 and fits x1, x4, x8 or x16 slots, so no alternative version is required — just ensure your OS is Windows 8, 10 or 11 for driver-free operation.
