Two black Mini SAS SFF-8643 to four SATA cables, 0.5 m each

Vszerda

Vszerda SFF-8643 to 4 SATA cable 2-pack 0.5 m

SKU CH-0C43-QK58Z

Connects a Mini SAS SFF-8643 port to four SATA drives at up to 6 Gbps, supplied as a 0.5 m black cable pair

  • TypeSATA
  • ColorBlack
  • Length0.5 - 1
  • Connector DetailMini Sas
  • Terminal GenderMale-to-Female
  • Speed6 gigabits_per_second
  • Connect host bus adapter or RAID controller to four SATA drives via SFF-8643
  • Stainless steel latches lock securely for reliable internal storage connections
  • 36-pin SFF-8643 to four 7-pin SATA connectors support 3 Gbps and 6 Gbps
  • Compatible with Adaptec RAID 71605 and 7895 storage controllers
  • Two 0.5 metre cables included for compact server or workstation builds

SFF-8643 breakout cable for four SATA drives

This cable set connects a host bus adapter, RAID controller or motherboard with an SFF-8643 port to up to four SATA hard drives or SSDs. Each pack contains two 0.5 metre cables, suited for compact server or workstation builds where internal space is limited. The 36-pin SFF-8643 connector uses stainless steel latches for a secure fit.

6 Gbps SATA link ceiling on each drive

The SFF-8643 interface can carry 12 Gbps SAS lanes, but the four 7-pin SATA connectors are limited to the SATA 6 Gbps standard. Every attached drive therefore tops out at 6 Gbps, and the cable cannot raise that ceiling. Builders planning a 12 Gbps SAS backplane will need a different breakout.

Four drives per cable with 0.5 m reach

Each cable fans out to four SATA targets, giving eight drive connections per pack within a half-metre radius of the controller. The short length keeps signal integrity high in dense chassis but rules out full-tower routing or external enclosures. Buyers needing longer runs or more than eight drives must look elsewhere.

Highlights

  • Connect host bus adapter or RAID controller to four SATA drives via SFF-8643
  • Stainless steel latches lock securely for reliable internal storage connections
  • 36-pin SFF-8643 to four 7-pin SATA connectors support 3 Gbps and 6 Gbps
  • Compatible with Adaptec RAID 71605 and 7895 storage controllers
  • Two 0.5 metre cables included for compact server or workstation builds

Specifications

BrandSonilco
ModelSFF-8643-4XSATA-0.5M-2PK
TypeSATA
ColorBlack
Length0.5 - 1
Connector DetailMini Sas
Terminal GenderMale-to-Female
Speed6 gigabits_per_second
FeaturesHigh Speed

Questions about this item

Which length should I choose for a compact server build?

Each cable in the pack measures 0.5 metres (1.6 feet), a short run that keeps airflow tidy in small-form-factor chassis.

What does the 6 Gbps rating mean once the cable is installed?

It carries SATA III traffic at up to 6 Gbps per drive, so four SSDs or HDDs can each run at full SATA III speed simultaneously.

How does the SFF-8643 interface limit real-world performance?

The 36-pin SFF-8643 host connector supports both 3 Gbps and 6 Gbps SATA, capping each attached drive at the SATA III maximum of 6 Gbps.
