Green SATA port multiplier board with five SATA 3.0 connectors and JMB575 chip

Vszerda

Vszerda SA-054-XY JMB575 5-port SATA 6Gbps multiplier

SKU CH-X5RG-97ER3

Connects five SATA drives to one host port using a JMB575 multiplier with 6Gbps speed and PM support

  • Typexiwai
  • ColorGreen
  • Length10 L x 10 W x 1 H centimeters
  • Speedata
  • Specificationscopper, SATA Devices with PM Function (e.g., Hard Drives, SS
  • Conductorcopper
  • Expands one host port into five SATA 6Gbps connections
  • Single JMB575 chip integrates five independent SATA channels and a micro-processor
  • Compliant with Port Multiplier 1.2 and Port Selector 1.0 specifications
  • Supports command-based and FIS-based switching for PM-aware and non-PM-aware hosts
  • Cascaded mode allows up to five drives on one host port

5-port SATA 6Gbps multiplier

The Vszerda SA-054-XY uses a JMB575 controller to turn one SATA host port into five independent SATA 3.0 connections. It targets builders who need more drive bays than their motherboard or add-in card provides and whose host controller supports port multiplier or selector operation.

Port multiplier requirement

The adapter only works when the host SATA port operates in port multiplier or selector mode; without that capability the connected drives will not be recognised. Compatible host chipsets include JMS582, JMB585, ASM1061, ASM1064 and ASM1166, and the device complies with Serial ATA Port Multiplier Spec 1.2 and Port Selector Spec 1.0.

Replacing single-port SATA connections

This multiplier replaces a direct one-to-one SATA cable when the system has a spare port multiplier-capable host connector but insufficient physical ports for five drives. The upgrade is worthwhile when the host controller and firmware both support multiplier operation and the workload can share the single 6Gbps upstream link.

Highlights

  • Expands one host port into five SATA 6Gbps connections
  • Single JMB575 chip integrates five independent SATA channels and a micro-processor
  • Compliant with Port Multiplier 1.2 and Port Selector 1.0 specifications
  • Supports command-based and FIS-based switching for PM-aware and non-PM-aware hosts
  • Cascaded mode allows up to five drives on one host port

Specifications

Brandxiwai
ModelSA-054-XY
Typexiwai
ColorGreen
Length10 L x 10 W x 1 H centimeters
Speedata
Specificationscopper, SATA Devices with PM Function (e.g., Hard Drives, SSDs, Optical Drives) with compatible chipsets, xiwai, SATA Host to 5-ESATA Card
Conductorcopper
Constructioncopper
Featurescopper, SATA Host to 5-ESATA Card, SATA Devices with PM Function (e.g., Hard Drives, SSDs, Optical Drives) with compatible chipsets

Questions about this item

Which version of this multiplier should I choose for a five-drive setup?

The SA-054-XY model provides five SATA 3.0 ports from a single host connection using the JMB575 chip, so one unit covers a five-drive array.

What does the 6 Gbps rating mean when the board is installed in my system?

Each of the five ports can run at SATA 3.0 6 Gbps, but the total bandwidth is shared across the single host link, so simultaneous transfers split that ceiling.

Which host controllers work with the port multiplier function?

Compatible host chipsets include JMS582, JMB585, ASM1061, ASM1064 and ASM1166, and the host port must be set to multiplier or selector mode.
