Small beige PLC splitter box with sixteen SC pigtails 0.9 mm singlemode 1 m length

Vszerda

Vszerda PLC Fiber Optical Splitter 1X16 0.9mm G657A1 Singlemode SC 1M

SKU CH-HM9M-CKHK0

A 1×16 PLC splitter distributes singlemode signals evenly across sixteen SC ports with 13.5 dB insertion loss and 50 dB return loss over 1310/1550 nm

  • TypeFiber Optic
  • Connector NumberSC
  • Uniform splitting for consistent signal delivery across 16 ports
  • Low 13.5 dB insertion loss with 50 dB return loss for stable performance
  • Operates reliably from -40 to 85 °C in harsh environments
  • Supports 1310 nm and 1550 nm wavelengths for flexible deployment
  • G657A1 singlemode fiber with SC connectors simplifies home and project wiring

Vszerda 1X16 PLC Splitter

The Vszerda 1X16 PLC fiber optical splitter divides a single singlemode input into sixteen equal outputs for passive optical networks. It uses G657A1 bend-insensitive fiber with SC connectors on 0.9 mm pigtails. The device suits FTTH deployments, campus LAN builds, and engineering projects that require uniform signal distribution to multiple endpoints.

Replaces cascaded couplers

A single 1X16 module replaces a tree of smaller splitters, reducing splice points and rack space in distribution frames. The jump is worthwhile when a PON designer needs sixteen drop cables from one feeder and wants insertion loss capped at 13.5 dB with return loss of 50 dB. Installers who only need two or four drops should choose a lower-split module instead.

Passive loss budget limits

The splitter adds 13.5 dB of insertion loss across the 1310 nm and 1550 nm windows, so the link budget must absorb that penalty before the ONT sensitivity threshold. Operating range spans -40 to 85 °C, but the steel cassette adds bulk compared to bare-fiber PLC chips. The 1 m pigtail length fixes the reach to the splice tray; longer tails require a separate patch cord.

Highlights

  • Uniform splitting for consistent signal delivery across 16 ports
  • Low 13.5 dB insertion loss with 50 dB return loss for stable performance
  • Operates reliably from -40 to 85 °C in harsh environments
  • Supports 1310 nm and 1550 nm wavelengths for flexible deployment
  • G657A1 singlemode fiber with SC connectors simplifies home and project wiring

Specifications

BrandPoyiccot
TypeFiber Optic
Connector NumberSC

Questions about this item

What fiber diameter and connector does the 1X16 splitter use?

The splitter uses 0.9 mm G657A1 singlemode fiber with SC connectors on all ports.

How is the 1X16 PLC splitter installed and what step is often missed?

Mount the stainless steel box, route the 1 m pigtails, then clean and inspect every SC ferrule before mating — skipping the cleaning step causes high insertion loss.

When should the 1X16 splitter be replaced based on its optical specs?

Replace it if insertion loss rises above 13.5 dB or return loss drops below 50 dB at 1310 nm or 1550 nm, indicating degraded splitting uniformity.
