Green PCIe x1 adapter card with M.2 slot and SATA port, silver bracket

Vszerda

Vszerda PCIe X1 to M.2 SATA + SATA III cable

SKU CH-QXRC-AAHPS

Adds a B-key M.2 SATA slot and a SATA III port via PCIe x1 using ASM1061 chipset

  • Connect M.2 SATA SSD and SATA HDD simultaneously
  • ASM1061 chipset delivers 6Gbps SATA III speed
  • Supports B-key and B+M-key M.2 sizes 2230 to 2280
  • PCIe X1 interface fits X2, X4, X8, X16 slots
  • Hot-swap capable with NCQ for responsive storage

PCIe X1 to M.2 SATA adapter

This Vszerda adapter adds an M.2 SATA slot and a standard SATA III port through a single PCIe X1 lane. It fits B-key and B+M-key drives in 2230, 2242, 2260 and 2280 lengths. The ASM1061 chipset handles both connections simultaneously. NVMe M.2 SSDs are not supported.

Capacity and headroom

The board runs at SATA 6 Gbps per port, matching the 3.2 specification. It accepts drives from 2230 up to 2280 form factors. Performance scales with the SSD controller and capacity. The PCIe X1 link limits combined throughput to roughly one lane of bandwidth.

Thermals, noise and power

Passive operation means no fan noise and no extra power connector. Heat comes only from the ASM1061 bridge and the attached drives. Standard case airflow is sufficient for typical workloads. Hot-swap support lets you change drives without shutting down.

Highlights

  • Connect M.2 SATA SSD and SATA HDD simultaneously
  • ASM1061 chipset delivers 6Gbps SATA III speed
  • Supports B-key and B+M-key M.2 sizes 2230 to 2280
  • PCIe X1 interface fits X2, X4, X8, X16 slots
  • Hot-swap capable with NCQ for responsive storage

Specifications

No published specifications for this item yet.

Questions about this item

Will this adapter let me add an M.2 SATA SSD and a SATA hard drive to my older PC that only has PCIe x1 slots?

Yes, the card uses a PCIe x1 connector that also fits x2, x4, x8 and x16 slots, and provides both an M.2 B-key SATA slot and a SATA III port for simultaneous use.

How can I verify the ASM1061 controller is recognised and both drives run at 6 Gbps after installation?

Check Device Manager for the ASM1061 SATA controller and confirm each drive negotiates SATA 6Gbps in the OS or BIOS.

Does the package include mounting brackets for a standard-height case and what else must I buy?

A standard-profile bracket is included; you must supply an M.2 B-key SATA SSD (2230, 2242, 2260 or 2280) and SATA data/power cables for the extra drive.
