Small green circuit board with M.2 B-key slot and 7+17P Apple connector

Vszerda

Vszerda M.2 SATA adapter for MacBook Air A1465 A1466

SKU CH-WKDJ-EBCN6

Converts a B-key M.2 SATA SSD to the 2012 MacBook Air 7+17-pin slot, supporting 2230, 2242, 2260 and 2280 form factors at SATA 6 Gbps

  • Upgrades 2012 MacBook Air A1465 A1466 with M.2 SATA SSD
  • Supports four B-key sizes 22×30 22×42 22×60 22×80 mm
  • Delivers SATA 3.0 6 Gbps throughput via 7+17-pin Apple connector
  • Compact 109×23.6×3 mm card fits original drive bay
  • Works with MD223 MD224 MD231 MD232 models only

2012 MacBook Air SSD Upgrade

This adapter lets owners of MacBook Air models A1465 and A1466 install a standard M.2 B-key SATA SSD. It converts the proprietary 7+17 pin Apple connector to a common M.2 slot. The card accepts four drive lengths: 2230, 2242, 2260 and 2280 millimetres. It is a direct mechanical and electrical replacement for the original 2012 flash module.

Replaces Original 2012 Flash Module

The board plugs into the exact 7+17 pin socket used on 2012 MacBook Air units MD223, MD224, MD231 and MD232. It is not compatible with 2013 to 2015 MacBook Air or Pro models because Apple changed the SSD pinout in 2013. The upgrade is worthwhile when the factory drive has failed or when more capacity is needed than the original module provided. Buyers with 2013 or newer machines cannot use this adapter.

Limited to SATA 3.0 6Gbps Throughput

The adapter runs at SATA 3.0 6Gbps and does not support NVME or PCIe protocol drives. Only B-key M.2 SATA SSDs will function; M-key or NVMe drives are electrically incompatible. Maximum sequential speed is therefore capped at the SATA 3.0 interface limit. The board operates in environments from minus thirty to seventy degrees Celsius.

Highlights

  • Upgrades 2012 MacBook Air A1465 A1466 with M.2 SATA SSD
  • Supports four B-key sizes 22×30 22×42 22×60 22×80 mm
  • Delivers SATA 3.0 6 Gbps throughput via 7+17-pin Apple connector
  • Compact 109×23.6×3 mm card fits original drive bay
  • Works with MD223 MD224 MD231 MD232 models only

Specifications

No published specifications for this item yet.

Questions about this item

What are the physical dimensions of the adapter card and which M.2 SSD lengths will fit?

The card measures 109 by 23.6 by 3 mm and accepts B-type M.2 SSDs in 22 by 30, 22 by 42, 22 by 60 and 22 by 80 mm sizes.

How do I install the adapter in a 2012 MacBook Air and what is the common mistake?

Remove the original SSD, insert the M.2 SATA drive into the KEY-B slot, then plug the adapter's 7+17P connector into the MacBook's proprietary socket; the frequent error is trying to use an NVMe or PCIe SSD which the adapter does not support.

Will I need to replace the adapter or SSD later, and what limits the upgrade path?

The adapter itself is passive and needs no maintenance; future capacity is limited to SATA 6 Gbps M.2 drives in the four supported lengths because NVMe and PCIe protocols are not compatible with this 2012 Apple interface.
