Two short internal Mini SAS cables with SFF-8087 male connectors on both ends, thin blue jacket, 0.5 m length

Vszerda

Vszerda Internal Mini SAS HD Cable SFF-8087 to SFF-8087 0.5m 2 Pack

SKU CH-V4D0-5PDD5

Two 0.5m Mini SAS HD SFF-8087 cables deliver 24Gbps aggregated bandwidth for internal server storage and RAID arrays

  • TypeInternal Mini SAS HD Cable
  • Color2PC
  • Length0.5
  • Connector Number8
  • Connector DetailSff-8087 to Sff-8087
  • Terminal GenderMale-to-Male
  • 6 Gbps per lane for fast server storage
  • 24 Gbps total bandwidth across four lanes
  • Zinc-alloy latch rated for 10000 insertions
  • 5 mm slim jacket fits 1U and 2U chassis
  • Works with 3 Gbps SAS 1.0 devices

Internal SAS cable for server storage

This 0.5m Mini SAS HD cable connects RAID controllers and backplanes inside 1U or 2U chassis. The male-to-male SFF-8087 connectors suit LSI 9211-8i, Dell PERC H310 and similar cards. Two cables are included for dual-port configurations. Builders needing longer runs or external ports should choose a different cable.

SAS 2.0 compliance at 6 Gbps per lane

Each cable carries four lanes at 6 Gbps, giving 24 Gbps aggregate bandwidth for HDD or SSD arrays. The design meets SAS 2.0 dual-mode specifications and remains backward compatible with 3 Gbps SAS 1.0 devices. No other speed rating applies to this part.

Sustained throughput in dense racks

Zinc-alloy locking latches rated for 10000 insertion cycles keep connections secure under vibration. The 4.5 mm jacket routes cleanly in tight spaces while the cable has been tested at 40°C and 90% RH. Signal integrity holds across the full length during continuous RAID rebuilds or backup streams.

Highlights

  • 6 Gbps per lane for fast server storage
  • 24 Gbps total bandwidth across four lanes
  • Zinc-alloy latch rated for 10000 insertions
  • 5 mm slim jacket fits 1U and 2U chassis
  • Works with 3 Gbps SAS 1.0 devices

Specifications

Brandipolex
TypeInternal Mini SAS HD Cable
Color2PC
Length0.5
Connector Number8
Connector DetailSff-8087 to Sff-8087
Terminal GenderMale-to-Male
Speed6 gigabits_per_second
SpecificationsInternal Mini SAS HD Cable
ShieldingData Transfer
FeaturesData Transfer

Questions about this item

What does the 6 Gbps per lane speed mean for my RAID array?

Each of the four lanes runs at 6 Gbps, giving 24 Gbps aggregate bandwidth for HDD or SSD backplanes connected to controllers such as LSI 9211-8i or Dell PERC H310.

Which SAS standard does the SFF-8087 connector follow and what does it limit?

The cable meets SAS 2.0 dual-mode compliance, so each lane is capped at 6 Gbps while remaining backward compatible with 3 Gbps SAS 1.0 devices.

Will the 0.5 m cable with its 4.5 mm jacket fit inside a 1U server chassis?

Yes, the ultra-slim 4.5 mm OD jacket and straight-to-straight design are built for tool-free routing in 1U and 2U racks such as HP ProLiant Gen8 and IBM xSeries.
