Two black braided cables with blue SFF-8643 plugs splitting to four SATA connectors each

Vszerda

Vszerda 2Pack Mini SAS HD SFF-8643 to 4 SATA Cable 0.5m

SKU CH-GVWP-8DHJ1

A two-pack of 0.5 m Mini SAS HD SFF-8643 to four SATA breakout cables with locking latches and braided 30 AWG conductors

  • TypeMini-SAS Cables
  • ColorBlack+Blue
  • Length1.6
  • ConductorCopper
  • FeaturesBraided
  • Connect up to four SATA drives via one SFF-8643 port
  • 12 Gbps SAS host link supports 6 Gbps per SATA drive
  • 5 m braided 30 AWG cable keeps routing tidy
  • Locking latches on both ends secure every connection
  • Two cables included for dual-controller or multi-bay setups

2-Pack Mini SAS HD SFF-8643 Breakout Cables

This two-pack provides two 0.5 metre cables that split a single SFF-8643 Mini SAS HD male connector into four SATA 7-pin female connectors. They are designed for system builders and storage professionals who need to connect a SAS RAID controller or HBA to up to eight SATA hard drives or SSDs using both cables.

Braided 30 AWG copper conductors

Each cable uses thin, flexible 30 AWG copper conductors wrapped in a braided sleeve for durability and easier routing inside a chassis. Both the SFF-8643 host end and the four SATA target ends feature locking latches to maintain a secure connection under vibration or during drive swaps.

SFF-8643 host to four SATA targets at 6 Gbps per

The SFF-8643 male connector plugs into a 12 Gbps SAS HBA or RAID controller, while each of the four SATA 7-pin female connectors supports a SATA III drive at up to 6 Gbps. Note that the Mini SAS HD connector must not be plugged into a backplane, or the cable will not function.

Highlights

  • Connect up to four SATA drives via one SFF-8643 port
  • 12 Gbps SAS host link supports 6 Gbps per SATA drive
  • 5 m braided 30 AWG cable keeps routing tidy
  • Locking latches on both ends secure every connection
  • Two cables included for dual-controller or multi-bay setups

Specifications

BrandADCAUDX
ModelHD MINISAS-004
TypeMini-SAS Cables
ColorBlack+Blue
Length1.6
ConductorCopper
FeaturesBraided

Questions about this item

How do I install the SFF-8643 to 4 SATA cable and what step is often missed?

Connect the SFF-8643 male end to the SAS RAID controller or motherboard and the four SATA 7-pin female ends to the drives; the step often missed is ensuring the locking latches on both the Mini SAS HD and each SATA connector click fully into place for a secure link.

What maintenance or replacement will this cable need later?

The braided 30 AWG copper conductors are passive and require no scheduled maintenance; replacement is only necessary if the locking latches break, the braid frays, or a connector pin is bent during a drive swap.

What limit appears first under sustained use with four drives?

Each SATA lane is rated at 6 Gbps while the SFF-8643 host side supports 12 Gbps SAS, so the per-drive 6 Gbps SATA ceiling is the first bottleneck when all four drives are active continuously.
