Rectangular metal power supply unit with 6-pin and 4-pin connectors, matte black finish

Vszerda

Vszerda 240W Power Supply H240ES-02 6Pin+4Pin Dell OptiPlex MT

SKU CH-G549-HP018

240W replacement PSU with 6-pin and 4-pin connectors for Dell OptiPlex Mini Tower models

  • 240 W output powers Dell OptiPlex and Vostro Mini Towers
  • 100–240 V AC input works on mains worldwide
  • 6-pin plus 4-pin connector matches original PSU layout
  • Replaces multiple Dell part numbers including J61WF and DK87P
  • Brand-new unit supplied in single-package format

Direct replacement for Dell OptiPlex MT

This Vszerda 240W power supply replaces the original H240ES-02 unit in Dell OptiPlex 3050 3060 3070 5050 5060 7050 7060 7070 Mini Tower and Vostro 3668 3669 systems. It matches the listed part numbers including J61WF DK87P and the wider H240 H260 H180 series. The unit delivers up to 240W from a 100-240V 50-60Hz input. It is built for owners who need a like-for-like swap in these specific chassis.

Proprietary 6Pin plus 4Pin connector

The adapter uses the Dell-specific 6Pin plus 4Pin connector arrangement required by the compatible OptiPlex and Vostro Mini Tower models. This pin layout means the unit plugs directly into the motherboard without adapters or cable modifications. The fixed cable harness keeps routing tidy inside the narrow MT case. Builders working on systems that use a different connector pin-out or a standard ATX 24-pin header cannot use this unit.

Steps up from 180W and 200W factory units

The 240W rating provides headroom over the 180W H180ES-00 HU180NS-00 H180AS-02 L180ES-01 L180AS-02 L180AS-03 and 200W B200AS-00 units originally fitted to some configurations. That extra capacity supports discrete graphics cards or additional drives that the lower-wattage models cannot sustain. If the existing power supply already carries a 240W or 260W label such as H260EPM-00 H260EBM-00 B260EBM-00 AC240AM-01 this replacement restores the same rating rather than increasing it.

Highlights

  • 240 W output powers Dell OptiPlex and Vostro Mini Towers
  • 100–240 V AC input works on mains worldwide
  • 6-pin plus 4-pin connector matches original PSU layout
  • Replaces multiple Dell part numbers including J61WF and DK87P
  • Brand-new unit supplied in single-package format

Specifications

No published specifications for this item yet.

Questions about this item

What AC input voltage and frequency does the 240W unit accept?

The power supply accepts 100-240V AC at 50-60Hz, drawing up to 4A, so it works on mains worldwide without a voltage switch.

What connector does the H240ES-02 use to plug into the motherboard?

It uses a combined 6Pin + 4Pin connector that matches the Dell OptiPlex Mini Tower power socket used on models such as the 3050, 5050 and 7050.

How do you install the replacement PSU in a Dell OptiPlex Mini Tower?

Remove the side panel, unplug the old unit's 6Pin+4Pin cable, unscrew the PSU from the chassis, fit the new unit, reconnect the same 6Pin+4Pin cable, and replace the panel.
