Vszerda 24-pin to 6-pin ATX adapter cable, 13-inch length, black connectors and sleeved wires

Vszerda

Vszerda 24 Pin to 6 Pin ATX Adapter Cable 13-inch (33cm)

SKU CH-9TY3-5002V

Converts a standard 24-pin ATX supply to the 6-pin HP motherboard connector used in Z220, Z230, ProDesk 600 G1 and EliteDesk 800 G1 workstations, 33 cm long

  • Converts standard 24-pin ATX PSU to 6-pin HP workstation power
  • 13-inch (33 cm) length fits SFF and tower chassis cleanly
  • 18 AWG tin-coated copper conductors deliver reliable current flow
  • Updated design eliminates fan-error beep on supported HP models
  • Compatible with HP Z220, Z230, ProDesk 600 G1, EliteDesk 800 G1 and listed series

HP Workstation Power Adapter

This 13-inch cable converts a standard 24-pin ATX supply to the 6-pin connector found on HP Z220, Z230 and EliteDesk 800 G1 systems. It is built for technicians and hobbyists who want to reuse an off-the-shelf power supply in a proprietary HP chassis. The adapter includes both standard and small 6-pin ends to match different motherboard headers. Ground-wire position on the 24-pin end may vary without affecting function.

18 AWG Gauge and Length Limits

Conductors are 18 AWG tin-coated copper rated to the 1007 specification, suitable for the typical loads of the listed workstations. The 33-centimetre reach fits small-form-factor and tower layouts where the power supply sits close to the motherboard. It cannot span the longer distances required by full-size ATX cases or dual-chassis server builds. Voltage drop becomes a concern if the cable is extended beyond this length.

No Extra Connectors Included

The adapter only bridges the main 24-pin to 6-pin transition; the separate ATX 4-pin CPU cable from the replacement supply must still reach the motherboard CPU header. Builders must verify that their chosen power supply provides that cable and that it routes cleanly inside the HP case. The updated design eliminates the fan-error beep on supported G1 models, but G2 small-form-factor units may still report a fan detection error.

Highlights

  • Converts standard 24-pin ATX PSU to 6-pin HP workstation power
  • 13-inch (33 cm) length fits SFF and tower chassis cleanly
  • 18 AWG tin-coated copper conductors deliver reliable current flow
  • Updated design eliminates fan-error beep on supported HP models
  • Compatible with HP Z220, Z230, ProDesk 600 G1, EliteDesk 800 G1 and listed series

Specifications

No published specifications for this item yet.

Questions about this item

Will this 13-inch 24-pin-to-6-pin adapter reach the motherboard connector inside my HP Z230 SFF?

The cable is 13 inches (33 cm) long, which is sized for SFF and MT chassis such as the Z220 and Z230 series.

How can I confirm the adapter is working after I install it in an EliteDesk 800 G1?

The updated design eliminates the fan-error beep; a successful POST with no beeping means the power handshake is correct.

Does the package include the separate ATX 4-pin CPU cable I must still connect?

No — the box contains only the 24-pin-to-6-pin adapter; the ATX 4-pin CPU cable comes from your replacement power supply.
