Green PCB adapter board with mSATA and M.2 B-key slots, SATA and USB 3.0 connectors, 2.5 inch form factor

Vszerda

Vszerda 2-in-1 mSATA / NGFF B-key to 2.5" SATA 3.0 Adapter with USB 3.0 Cable

SKU CH-4Z2A-7WMGS

Converts one mSATA or B-key NGFF SATA SSD to a 2.5″ SATA drive with an included USB 3.0 cable

  • Connect mSATA and NGFF B-key SSDs via SATA 3.0
  • Includes USB 3.0 cable for external drive access
  • NGFF B-key or B/M-key only — no M-key NVME support
  • 5-inch form factor 98 x 65.5 mm fits standard drive bays
  • Mini PCI-e 52-pin and M.2 B-key connectors built onto PCB

Dual-slot mSATA and NGFF B-key adapter

This adapter converts one mSATA SSD or one NGFF B-key SATA SSD into a standard 2.5 inch SATA 3.0 form factor. It includes a SATA to USB 3.0 cable for external connection to a PC. Only one drive can be active at a time.

Suits owners of legacy mSATA

Builders who need to run both an mSATA and an NGFF drive simultaneously should look elsewhere. Users with M-key NVMe SSDs cannot use this adapter. The NGFF slot accepts B-key or B/M-key SATA modules only.

Check your drive keying

Verify the M.2 SSD is B-key or B/M-key and uses the SATA protocol, not NVMe. Confirm the target system has a free SATA port or USB 3.0 port for the included cable. The board measures 98 by 65.5 mm and draws up to 3A.

Highlights

  • Connect mSATA and NGFF B-key SSDs via SATA 3.0
  • Includes USB 3.0 cable for external drive access
  • NGFF B-key or B/M-key only — no M-key NVME support
  • 5-inch form factor 98 x 65.5 mm fits standard drive bays
  • Mini PCI-e 52-pin and M.2 B-key connectors built onto PCB

Specifications

No published specifications for this item yet.

Questions about this item

What type of SSD must I already have for the M.2 (NGFF) B-key slot to accept it?

You need a B-key or B/M-key SATA SSD; the slot cannot accept an M-key NVME drive.

If I keep an mSATA drive installed, will the NGFF SATA SSD still function when both are inserted?

The NGFF SATA SSD takes priority and the mSATA drive will not operate while both are present.

How can I verify the adapter is delivering power correctly after connecting it?

The board supports up to 3 A output current; a drive that spins up and is recognised by the system confirms normal operation.
