Black rectangular box with two HDMI inputs and two HDMI outputs, IR sensor on front

Vszerda

Vszerda 2×2 HDMI Matrix Switch 4K@60Hz 18Gbps IR Remote (OZJ3)

SKU CH-ZZ6M-WAN30

Routes two HDMI sources to two displays independently or mirrored at 4K@60Hz with HDR and 18Gbps bandwidth

  • Routes any of two sources to two displays independently
  • Splits one source to both screens simultaneously with no delay
  • Delivers 4K 60 Hz YUV 4:2:0 video at 18 Gbps bandwidth
  • Handles 7.1-channel LPCM, Dolby and DTS audio formats
  • Includes IR remote for front-panel-free switching

What this matrix switch does

The Vszerda 2×2 HDMI matrix switch connects two HDMI sources to two displays and routes either source to either display independently. It also duplicates a single source across both outputs for mirrored viewing. The unit handles resolutions up to 3840×2160 at 60 Hz with YUV 4:2:0 colour sampling and an 18 Gbps data rate. It is suited for installers and home users who need flexible distribution without signal degradation.

Sustained-load behaviour

During continuous operation the switch maintains stable 4K@60 Hz throughput with no frame drops or flashing reported in the specifications. HDCP 1.4 compliance ensures protected content passes through both outputs without interruption. The device does not support HDCP 2.2, so newer protected streams may be blocked. Deep-colour modes up to 48 bit and LPCM 7.1 audio remain active across extended sessions.

Thermals, noise and power

The unit draws a maximum of 600 mA from its 5 V DC supply, equating to 3 W of power consumption. With no internal fan, it operates silently in typical environments. The specified operating range spans -15 °C to +45 °C, indicating the chassis dissipates heat passively within that window. No active cooling or audible noise is produced under normal use.

Highlights

  • Routes any of two sources to two displays independently
  • Splits one source to both screens simultaneously with no delay
  • Delivers 4K 60 Hz YUV 4:2:0 video at 18 Gbps bandwidth
  • Handles 7.1-channel LPCM, Dolby and DTS audio formats
  • Includes IR remote for front-panel-free switching

Specifications

No published specifications for this item yet.

Questions about this item

Does the 18 Gbps matrix run warm or draw much power when both displays stay on all day?

It draws a maximum of 600 mA from the 5 V supply and is rated for continuous use up to 45 °C ambient temperature.

Which cables and power source must I already have to connect two sources and two screens?

You need four HDMI cables for the two inputs and two outputs plus the included 5 V DC power adapter.

Will my older 1080P monitor and 4K@60 Hz TV both work correctly through the same HDCP 1.4 switch?

Yes, the matrix handles 1080P and 4K@60 Hz YUV 4:2:0 simultaneously and down-scales automatically for each display.
