Small rectangular metal module with screw terminals and network port, matte grey finish

VERACITY

VERACITY VHW-HW Highwire Ethernet over Coax Converter Module

SKU CH-H26S-TNTHR

Converts existing 75 Ohm coaxial cable into a 10/100 Ethernet link up to 500 metres with auto-configuring speed, duplex and polarity detection in an 84 x 54 x 24 mm module powered from 10-40 V DC

  • TypeTransceiver/Media Converter
  • Reuse existing coax cable to deploy IP cameras
  • Up to 500 m full-rate over RG-11 coaxial cable
  • Auto-negotiates 10/100 Mbps speed and duplex mode
  • Wide 10-40 V DC or 20-28 V AC power input
  • Compact 84 x 54 x 24 mm module fits tight spaces

Coax-to-Ethernet Media Converter

The VERACITY VHW-HW Highwire module converts existing 75 Ohm coaxial cable into a 10 or 100 Mbps Ethernet link. It auto-optimises for RG-59 up to 280 metres, RG-6 up to 350 metres and RG-11 up to 500 metres at full rate. No user configuration is required and the unit auto-detects speed, duplex, cable type and polarity. Power input accepts 10 to 40 V DC or 20 to 28 V AC.

Installers Upgrading Analogue Camera Systems

This converter suits projects that replace analogue cameras with IP units while reusing installed coax, avoiding the cost and disruption of new network cabling. It is not intended for runs exceeding the stated cable-length limits or for applications that require gigabit throughput. Buyers needing fibre uplinks or managed-switch features should consider other equipment.

Detachable Screw-Terminal Connector

The supplied screw-terminal block simplifies coax termination and can be removed for bench testing or tight enclosures. Its auto type and polarity detection eliminates wiring errors during installation. No additional software, licences or configuration tools are bundled with the hardware.

Highlights

  • Reuse existing coax cable to deploy IP cameras
  • Up to 500 m full-rate over RG-11 coaxial cable
  • Auto-negotiates 10/100 Mbps speed and duplex mode
  • Wide 10-40 V DC or 20-28 V AC power input
  • Compact 84 x 54 x 24 mm module fits tight spaces

Specifications

BrandVERACITY
ModelVHW-HW
TypeTransceiver/Media Converter
Shipping weight0.09 kg
Package size254 × 127 × 127 mm

Questions about this item

What existing cable does the VHW-HW need to operate over?

It operates over any 75 Ohm coaxial cable such as RG-59, RG-6 or RG-11 already installed for analogue video.

Can the VHW-HW connect to a legacy 10BASE-T switch port?

Yes, it auto-configures for 10BASE-T or 100BASE-T speed and duplex, so it will link with older 10 Mb/s equipment.

How can I confirm the VHW-HW has established a full-rate link after installation?

A successful link reaches 280 m on RG-59, 350 m on RG-6 or 500 m on RG-11 at full 100BASE-T rate.
