Three inch CPVC ball valve union, white plastic body with lever handle, socket and FNPT connections

Value Brand

Value Brand 3" CPVC Ball Valve Union Socket/FNPT

SKU CH-N8M7-VTDE0

A 3-inch CPVC ball valve with socket and FNPT connections, full-port design, and 150 psi pressure rating

  • TypeOther
  • Full-port design maintains unrestricted flow through 3-inch piping
  • CPVC body and ball resist corrosion in hot water systems
  • PTFE seats provide reliable sealing up to 150 psi pressure
  • Lever handle allows quick manual operation with CPVC durability
  • Rated for continuous service from 32 to 194 degrees F

3-inch CPVC Ball Valve for piping systems

This 3-inch CPVC ball valve uses a socket and FNPT union connection for joining CPVC pipe in industrial or commercial plumbing. The full-port design allows unrestricted flow through the valve body. It suits installers needing a corrosion-resistant shut-off valve for chemical or water applications.

Pressure and temperature limits for CPVC service

The valve handles a maximum working pressure of 150 psi CWP. Operating temperatures range from 32 to 194 degrees Fahrenheit. PTFE seats and FPM body seals provide chemical compatibility within these limits. Exceeding the pressure or temperature rating risks seal failure or body deformation.

Socket and FNPT union installation notes

The single union and true union, 2-piece body allows the valve to be removed from the line without cutting pipe. Solvent-cement the socket ends to CPVC pipe and thread the FNPT connections to mating fittings. Over-tightening threads or insufficient cement cure time are common causes of leaks. The lever handle is CPVC and operates the CPVC ball and stem.

Highlights

  • Full-port design maintains unrestricted flow through 3-inch piping
  • CPVC body and ball resist corrosion in hot water systems
  • PTFE seats provide reliable sealing up to 150 psi pressure
  • Lever handle allows quick manual operation with CPVC durability
  • Rated for continuous service from 32 to 194 degrees F

Specifications

BrandZORO SELECT
TypeOther

Questions about this item

Which valve size should I choose for a three-inch CPVC line?

This listing covers the 3-inch pipe size with a socket and FNPT union combination; select it when your system uses three-inch CPVC pipe and fittings.

What does the 150 psi CWP rating mean once the valve is installed?

It indicates the valve can handle up to 150 psi cold working pressure in a CPVC piping system at normal operating temperatures.

What temperature range does the CPVC body and PTFE seat support in practice?

The valve is rated for continuous service from 32 to 194 degrees Fahrenheit, covering typical hot and cold water applications.
