Five black S-video PCB sockets with silver pins 14 x 13 x 17mm

Unique-Bargains

Unique-Bargains S-video PCB Mount 4 Pin Mini Din Socket Black 5Pcs

SKU CH-FY8F-FK1J6

Five S-video PCB-mount sockets with four-pin mini-DIN female connectors measuring 14 x 13 x 17 mm

  • Compact 14 x 13 x 17 mm footprint fits tight PCB layouts
  • Four-pin female Mini-DIN restores S-video connectivity on damaged boards
  • Five-piece pack provides spares for multiple repairs or prototyping
  • Plastic-and-metal construction resists wear from repeated cable insertion
  • Suitable for media players, notebooks, car audio and other AV gear

S-video PCB socket pack

This pack contains five female 4-pin Mini DIN sockets designed for through-hole PCB mounting. They suit repair technicians and hobbyists who need to replace damaged S-video connectors on consumer electronics boards.

4-pin Mini DIN footprint

Each socket measures 14 by 13 by 17 millimetres with a black plastic body and silver-tone pins. The 4-pin arrangement matches the standard S-video signal layout used on many legacy audio-video devices.

Ideal for legacy AV repairs

Buyers restoring media players, portable audio gear or older notebook docks will find the correct footprint here. Anyone needing a 7-pin mini-DIN, a panel-mount jack or a surface-mount variant should look elsewhere.

Highlights

  • Compact 14 x 13 x 17 mm footprint fits tight PCB layouts
  • Four-pin female Mini-DIN restores S-video connectivity on damaged boards
  • Five-piece pack provides spares for multiple repairs or prototyping
  • Plastic-and-metal construction resists wear from repeated cable insertion
  • Suitable for media players, notebooks, car audio and other AV gear

Specifications

BrandUnique Bargains

Questions about this item

What does the 4-pin Mini-DIN layout carry when soldered to a board?

It provides the standard S-video luminance and chrominance signals plus ground connections for analogue video equipment.

Which mounting style and pitch does the socket use for PCB installation?

Through-hole PCB mount with pins spaced to the 14 x 13 mm body footprint.

How much board space and clearance does each socket need?

Each unit occupies 14 x 13 mm on the board and stands 17 mm tall once soldered.
