Ubiquiti Networks BulletAC-IP67 network antenna
Dual-band AC radio with IP67 enclosure supports selectable channel widths from 10 to 80 MHz for long-range PtP and PtMP links
- Zero-variable deployment with no RF cables or special tools required
- Flexible channel bandwidths from 10 to 80 MHz for PtP links
- IP67-rated enclosure built for outdoor durability
- airOS 8 operating system with airMAX ac protocol support
- Automatic channel selection and transmit power control for optimised performance
Dual-Band AC Outdoor Radio
The BulletAC-IP67 is an airMAX ac radio built for outdoor point-to-point and point-to-multipoint links. It integrates the radio and antenna in a single IP67-rated enclosure so installers can mount it directly on a mast or pole. The unit runs airOS 8 and supports WPA2 security for carrier-grade deployments.
Zero-Cable Deployment
The all-in-one design removes the need for separate RF cables, antenna assemblies or specialised mounting hardware. There are no radio-card compatibility issues and no cable-loss calculations to manage. Power is supplied over Ethernet, so a single cable run handles both data and power for the link.
Selectable Channel Widths Under Load
Operators can choose channel widths of 10, 20, 30, 40, 50, 60 or 80 MHz for point-to-point links and 10, 20, 30 or 40 MHz for point-to-multipoint sectors. Automatic channel selection, transmit power control and ACK timing adjustment maintain link stability during sustained traffic. Buyers needing integrated GPS sync or multi-gigabit Ethernet ports should evaluate other models.
Highlights
- Zero-variable deployment with no RF cables or special tools required
- Flexible channel bandwidths from 10 to 80 MHz for PtP links
- IP67-rated enclosure built for outdoor durability
- airOS 8 operating system with airMAX ac protocol support
- Automatic channel selection and transmit power control for optimised performance
Specifications
No published specifications for this item yet.
Questions about this item
What channel-width ceiling limits sustained throughput on a long-range PtP link?
The radio supports PtP channel widths up to 80 MHz, with selectable steps at 10, 20, 30, 40, 50 and 60 MHz.
How does the sealed IP67 housing handle heat and noise during continuous operation?
The integrated design removes RF cables and external enclosures, so heat dissipates through the metal body without any fan noise.
Which mounting hardware and power source must already be on site for the radio to operate?
A standard pole mount and a passive PoE injector are required; the unit ships without either.
