Black steel wall-mount rack cabinet with vented sides and front glass door

Tripp Lite

Tripp Lite SRW9U 9U Wall-Mount Server Rack 16.5in Deep

SKU CH-HNXM-B7E32 MPN SRW9U

Wall-mount steel cabinet secures 9U of 19 in. rack equipment up to 16.5 in. deep with 200 lb capacity and flow-through ventilation

  • TypeWall Mount Cabinet
  • Rack Units9U
  • ColorBlack
  • Weight Capacity200.00 lbs.
  • FeaturesMaximum load capacity of 200 lbs. Locking steel cabinet vent
  • Included AccessorySRW9U SmartRack 9U Low-Profile Switch-Depth Wall-Mount Rack
  • Secures 9U of 19-inch rack gear up to 16.5 in. deep
  • Supports 200 lbs. of equipment with rated load capacity
  • Locking steel cabinet with vented sides, front, top and bottom for airflow
  • Mounts on wall or rolls on floor with optional casters
  • Includes 12 M6 screws, 12 cage nuts, 12 cup washers, 12-24 screws, mounting plate and keys

9U wall-mount rack for 19-inch equipment

The Tripp Lite SRW9U is a locking steel cabinet that secures nine rack units of 19-inch gear up to 16.5 inches deep. It mounts directly to a wall and supports a maximum load of 200 lbs. The enclosure includes twelve M6 screws, twelve M6 cage nuts, twelve M6 cup washers, twelve 12-24 screws, a removable mounting plate, three mounting-plate screws and two keys. Builders who need deeper equipment bays or floor-standing capacity will need a different solution.

Vented enclosure with flow-through cooling

The cabinet is vented at the sides, front, top and bottom to create flow-through ventilation that keeps installed equipment cool during normal operation. No active fans are included, so airflow relies on passive convection and any fans inside the mounted devices. The unit weighs 35.00 lbs and measures 19.88 by 23.62 by 17.78 inches, leaving enough internal depth for typical network switches and patch panels.

Sustained load within the 200 lb rating

Under continuous full load the welded steel frame maintains structural integrity up to the rated 200.00 lbs without deformation. The locking front door and perforated panels remain secure during prolonged use, and the vent pattern sustains passive airflow without additional hardware. Optional SRCASTER wheels can convert the cabinet for floor rolling if relocation becomes necessary.

Highlights

  • Secures 9U of 19-inch rack gear up to 16.5 in. deep
  • Supports 200 lbs. of equipment with rated load capacity
  • Locking steel cabinet with vented sides, front, top and bottom for airflow
  • Mounts on wall or rolls on floor with optional casters
  • Includes 12 M6 screws, 12 cage nuts, 12 cup washers, 12-24 screws, mounting plate and keys

Specifications

BrandTripp Lite
ModelSRW9U
TypeWall Mount Cabinet
Rack Units9U
ColorBlack
Weight Capacity200.00 lbs.
FeaturesMaximum load capacity of 200 lbs.
Locking steel cabinet vented at sides, front, top and bottom
Flow-through ventilation keeps equipment cool
Secures 9U of 19 in. rack equipment up to 16.5 in. deep
Mounts to wall or rolls on floor (with optional SRCASTER)
Included AccessorySRW9U SmartRack 9U Low-Profile Switch-Depth Wall-Mount Rack Enclosure Cabinet
12 x M6 screws
12 x M6 cage nuts
12 x M6 cup washers
12 x 12-24 screws
Removable mounting plate
3 x Mounting plate screws
2 x Keys
Owner’s manual
Unit Dimension19.88" x 23.62" x 17.78"
Unit Weight35.00 lbs.
Shipping Dimension22.60" x 20.60" x 26.40"
Shipping Weight39.00 lbs.
Shipping weight17.78 kg
Package size660 × 584 × 521 mm

Questions about this item

How do I mount the 35.00 lb cabinet to the wall using the removable mounting plate, and what step is often missed?

Bolt the mounting plate to studs with suitable lag bolts, hang the cabinet on the plate, then secure it with the three included mounting-plate screws — the step often missed is fastening those three screws after hanging.

What hardware will need replacement if I re-configure the 9U of 19 in. rack space later?

The package includes 12 M6 screws, 12 M6 cage nuts, 12 M6 cup washers and 12 12-24 screws; any lost or damaged cage nuts or screws would need to be replaced.

At what load does the 200.00 lb weight capacity become the limiting factor during sustained use?

The cabinet is rated for a maximum load capacity of 200.00 lbs; exceeding that limit is the first constraint under sustained use.
