Black 12U wall-mount server rack with clear acrylic front window and hinged back, 20.5in deep

Tripp Lite

Tripp Lite SRW12USG 12U Wall-Mount Server Rack 20.5in Deep

SKU CH-T9DS-C69SG MPN SRW12USG

Wall-mount cabinet holds 12U of 19-inch equipment up to 20.5 inches deep, swings on a hinge for rear access, and includes a lockable acrylic front window

  • TypeWall Mount Cabinet
  • Rack Units12U
  • ColorBlack
  • FeaturesSaves Valuable Workspace Perfect for network wiring closets,
  • Included AccessorySRW12USG SmartRack 12U Low-Profile Switch-Depth Wall-Mount R
  • Unit Dimension63.50" x 23.62" 21.60"
  • Secures 12U of 19-inch rack gear up to 20.5in deep
  • Holds up to 200lb of equipment in a single cabinet
  • Hinged back swings away for full rear access during service
  • Locking front door with shatter-resistant acrylic window for monitoring
  • Vented steel sides, top and bottom maintain airflow while locked

12U Wall-Mount Rack for 19-Inch Equipment

The Tripp Lite SRW12USG is a 12U wall-mount enclosure that holds standard 19-inch rack gear up to 20.5 inches deep. It targets network closets, classrooms, retail back offices and other sites where floor space is unavailable but secure, organised equipment storage is required. The cabinet ships with M6 and 12-24 mounting hardware plus two keys. Builders needing deeper chassis or higher density should look elsewhere.

Hinged Access With Vented Steel Construction

The cabinet swings away from the wall on a hinge so technicians can reach rear cabling without removing the unit. Locking steel panels are vented at the sides, top and bottom to promote passive airflow through the enclosure. A shatter-resistant clear acrylic window in the front door allows visual monitoring of status LEDs while the doors remain locked. No active cooling or fan mounts are described in the specifications.

200-Pound Load Rating With Included Hardware

Heavy-duty steel finished in black powder coat supports a maximum load of 200 pounds across the 12U vertical space. The package supplies twenty M6 screws, twenty M6 cage nuts, twenty M6 washers and twenty 12-24 screws for equipment mounting. Overall dimensions are 63.50 by 23.62 by 21.60 inches and the unit weighs 59.99 pounds. Installers must verify that the mounting surface can bear the combined weight.

Highlights

  • Secures 12U of 19-inch rack gear up to 20.5in deep
  • Holds up to 200lb of equipment in a single cabinet
  • Hinged back swings away for full rear access during service
  • Locking front door with shatter-resistant acrylic window for monitoring
  • Vented steel sides, top and bottom maintain airflow while locked

Specifications

BrandTripp Lite
ModelSRW12USG
TypeWall Mount Cabinet
Rack Units12U
ColorBlack
FeaturesSaves Valuable Workspace
Perfect for network wiring closets, retail locations, classrooms, back offices and other areas with limited floor space where you need equipment to be secure, organized and out of the way
Houses EIA-standard 19 in. rack equipment in 12U of space
Maximum load capacity of 200 lbs.
Hinged Cabinet for Convenient Access
Swings away from the wall to allow easy back-door access to equipment and cabling during installation and maintenance
Rotate cabinet 180 degree before mounting to open reversible doors left or right
Shatter-Resistant Clear Acrylic Front Window
Lets
Included AccessorySRW12USG SmartRack 12U Low-Profile Switch-Depth Wall-Mount Rack Enclosure Cabinet
(20) M6 screws
(20) M6 cage nuts
(20) M6 washers
(20) 12-24 screws
(2) Keys
Owner’s manual
Unit Dimension63.50" x 23.62" 21.60"
Unit Weight59.99 lbs.
Shipping weight29.48 kg
Package size706 × 664 × 622 mm

Questions about this item

How is the 12U wall-mount cabinet secured to the wall, and what step do installers often miss?

The cabinet must be lag-bolted through its mounting holes into studs or concrete anchors rated for the 59.99 lb unit plus 200 lb load; the step often missed is verifying the wall structure can handle the combined weight before drilling.

Which components will need inspection or replacement over the life of the SRW12USG?

The hinge pins, door locks, acrylic window latches, and cage-nut threads should be checked periodically; the included M6 and 12-24 screws may need replacement if stripped during equipment changes.

What is the first limit reached when the cabinet is fully loaded and running continuously?

The 200 lb maximum load capacity is the primary structural limit; exceeding it risks hinge deformation or wall-mount failure before any other factor becomes critical.
