Tripp Lite 25U wall-mount server rack enclosure, black metal frame with vented top panel, front and rear doors, no side panels

Tripp Lite

Tripp Lite SR25UBEXP 25U Wall Mount Server Rack

SKU CH-KKWH-9819B MPN SR25UBEXP

A 25U wall-mount cabinet that holds 3000 lb of 19-inch gear, bayable via integrated tabs and adjustable rails from 4 to 37 inches deep

  • TypeWall Mount Cabinet
  • Rack Units25U
  • SpecificationForm Factor:19" 25U
  • FeaturesPackage Contents: 25U SmartRack Premium Enclosure (No Side P
  • Unit DimensionHeight:49.0" x Width:23.6" x Depth:43.0"
  • Unit Weight163.00 lb
  • Bay up to 3000 lb of 19-inch gear in 25U
  • Adjust rails from 4 to 37 inches without measuring
  • Vented roof panel pulls hot air out by convection
  • Tool-free 0U slots hold four PDUs or cable managers
  • Expansion unit bays side-by-side with integrated tabs

Expansion-Ready 25U Wall Cabinet

The SR25UBEXP is a 25U wall-mount enclosure designed to expand an existing row of server cabinets. It ships with doors and a roof but without side panels, using integrated baying tabs to join adjacent units. The cabinet accepts standard 19-inch EIA-310-E equipment and supports up to 3000 lbs of installed hardware.

Quarter-Inch Rail Adjustment

Front and rear vertical rails adjust in quarter-inch increments from 4 to 37 inches deep, and a depth index lets installers match positions without repeated measuring. Each rack space is numbered for quick reference, and two rails include toolless button-mount slots for up to four compatible 0U PDUs or cable managers. The package includes 50 M6 cage nuts, 50 M6 screws, stabilising brackets and keys.

Convection-Cooled Vented Top

A vented top panel promotes passive airflow, drawing cool air in and exhausting warm air out to help maintain equipment temperatures under sustained load. The 43.0-inch overall depth provides room for deeper servers and cable runs, while the 49.0-inch height and 23.6-inch width fit the 25U capacity within a 163.00 lb frame.

Highlights

  • Bay up to 3000 lb of 19-inch gear in 25U
  • Adjust rails from 4 to 37 inches without measuring
  • Vented roof panel pulls hot air out by convection
  • Tool-free 0U slots hold four PDUs or cable managers
  • Expansion unit bays side-by-side with integrated tabs

Specifications

BrandTripp Lite
ModelSR25UBEXP
TypeWall Mount Cabinet
Rack Units25U
SpecificationForm Factor:19" 25U
FeaturesPackage Contents:
25U SmartRack Premium Enclosure (No Side Panels Included)
2 x Accessory Mounting Rails
50 x M6 Cage Nuts
50 x M6 Screws
Stabilizing Brackets
Keys
Owner's Manual
Unit DimensionHeight:49.0" x Width:23.6" x Depth:43.0"
Unit Weight163.00 lb
Shipping weight90.72 kg
Package size1359 × 1073 × 603 mm

Questions about this item

How can I confirm the SR25UBEXP is holding its rated 3000lb load after installation?

Verify that the front and rear vertical rails are locked at the same depth index marking between 4 and 37 inches, that all 50 M6 cage nuts and screws are seated in the numbered 19-inch EIA-310-E square holes, and that the stabilizing brackets are fastened to the wall structure.

What ships with the SR25UBEXP and what must I order separately for a stand-alone cabinet?

The box includes the 25U enclosure without side panels, two accessory mounting rails, 50 M6 cage nuts, 50 M6 screws, stabilizing brackets, keys, and the owner's manual; side panels and any baying hardware for additional cabinets are sold separately.

Which SR25UBEXP configuration should I choose for a 25U, 3000lb wall-mount row expansion?

Select the SR25UBEXP expansion model; it provides 25U of 19-inch EIA-310-E square-hole mounting, adjustable rails from 4 to 37 inches, a vented top panel, and integrated baying tabs for joining multiple enclosures in a row.
