Metal 1U rackmount switch with 16 front ports

TRENDnet

TRENDnet TPE-TG160g 16-port gigabit PoE+ network switch

SKU CH-TEXT-5VDYE MPN TPE-TG160g

A 16-port Gigabit PoE+ switch with 246 W power budget and 32 Gbps switching capacity in a rack-mountable metal housing

  • StandardsIEEE 802.1p IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3ab
  • Uplink PortsNone
  • Primary Ports16 x Gigabit PoE/PoE+ ports
  • Primary Port Speed10/100/1000Mbps
  • MAC Address Table8K
  • Jumbo Frames10KB

Total Ports 16-Port

Struck-through versions exist but are not stocked here.

Style Desktop Switch

Struck-through versions exist but are not stocked here.

  • 16 Gigabit PoE+ ports power and connect devices over one cable
  • 246 W PoE budget supports many high-draw devices simultaneously
  • 32 Gbps switching capacity handles heavy traffic without bottlenecks
  • Sturdy 1U metal chassis with rack-mount brackets fits standard 19" cabinets
  • Smart fans cool the switch quietly across 0–40 °C operating range

16-Port Gigabit PoE+ Switch

The TRENDnet TPE-TG160g provides sixteen Gigabit Ethernet ports with PoE+ support. It delivers data and power over a single cable to devices such as wireless access points, IP cameras and VoIP phones. A 246 W PoE budget and 32 Gbps switching capacity handle demanding network loads. The 1U metal chassis includes rack-mount brackets for standard 19-inch cabinets.

Upgrade from non-PoE or lower-budget switches

Replacing a standard switch removes the need for separate power injectors or midspans. The jump is worthwhile when deploying PoE devices that require up to 30 W per port under IEEE 802.3at. Installations limited to 15.4 W per port under IEEE 802.3af gain extra headroom for newer endpoints. Networks without rack space or those needing uplink ports should consider other form factors.

Capacity and headroom

The 246 W budget comfortably powers sixteen 802.3af devices or a mix of 802.3at endpoints within the total limit. An 8K MAC address table and 10 KB jumbo frame support suit typical business traffic. Buffer memory of 512 KB absorbs burst traffic without loss. Smart fans regulate temperature from 0 °C to 40 °C. Environments requiring more than sixteen ports or a higher PoE budget exceed this model's capabilities.

Highlights

  • 16 Gigabit PoE+ ports power and connect devices over one cable
  • 246 W PoE budget supports many high-draw devices simultaneously
  • 32 Gbps switching capacity handles heavy traffic without bottlenecks
  • Sturdy 1U metal chassis with rack-mount brackets fits standard 19" cabinets
  • Smart fans cool the switch quietly across 0–40 °C operating range

Specifications

BrandTRENDnet
ModelTPE-TG160g
StandardsIEEE 802.1p
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3af (15.4 Watts/port)
IEEE 802.3at (30 Watts/port)
IEEE 802.3a
Uplink PortsNone
Primary Ports16 x Gigabit PoE/PoE+ ports
Primary Port Speed10/100/1000Mbps
MAC Address Table8K
Jumbo Frames10KB
Buffer Memory512KB
ProtocolsTCP/IP
PowerInput: 110-240 V AC, 50/60 Hz, 54 V/4.82 A; 12 V/1.67 A
Consumption: 36 Watts (Max. without PD)
Dimensions1.70" x 17.30" x 8.30" (H x W x D)
Weight6.80 lbs.
Temperature0°C to 40°C (32°F to 104°F)
Humidity90% Maximum, Non-condensing
Features16 x Gigabit PoE+ ports
246 W PoE budget
32 Gbps switching capacity
Sturdy metal switch
Rack mount brackets included
Package ContentsTPE-TG160g
Quick Installation Guide
Rack mount kit
Power cord
Shipping weight3.92 kg
Package size554 × 305 × 99 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What rack space and width does the 1U metal housing require?

The switch fits a standard 19-inch rack and occupies 1U of vertical space at 1.70 inches high, 17.30 inches wide and 8.30 inches deep.

How do I power the unit and connect PoE devices without exceeding the 246 W budget?

Plug the included power cord into a 110-240 V AC outlet; the internal supply delivers up to 246 W across the 16 PoE+ ports, so add device draws before connecting all ports.

Do the smart fans need cleaning or filter changes over time?

The built-in smart fans are maintenance-free; keep the ventilation openings clear of dust and operate within 0°C to 40°C for reliable cooling.
