White rectangular PoE injector with two RJ45 ports and power socket, wall-mountable, 4.9 by 2.3 by 1.4 inches

TP-Link

TP-Link POE5460X 54V 60W 10G Passive PoE Adapter

SKU CH-BPWT-VDBA5 MPN POE5460X

Delivers 54 V DC at up to 60 W over a single 10 Gbps RJ-45 link for passive PoE devices

  • Delivers up to 60 W of power for demanding passive PoE devices
  • Supports 10 Gbps data rates over a single RJ-45 connection
  • Compact wall-mountable design measuring 4.9" × 2.3" × 1.4" for flexible placement
  • Compliant with CE, FCC, BSMI, KC and multiple IEEE 802.3 standards for broad compatibility
  • Includes power cord and installation guide for immediate deployment

54V 60W 10G Passive PoE Adapter

The TP-Link POE5460X is a passive Power over Ethernet injector delivering 54V DC at up to 1.11A for 60W total output. It combines data and power on a single RJ-45 link at 10G speeds. The wall-mountable unit suits installers powering compatible passive PoE access points or cameras where no outlet exists nearby.

Replaces separate power bricks and midspan injectors

This adapter consolidates a data switch port and a 60W supply into one device, cutting cable count and eliminating the need for a local AC socket at the powered device. The jump is worth it when deploying passive PoE gear that demands 54V and cannot use standard 802.3af/at negotiation. It does not suit equipment requiring active PoE handshake or voltages below 45V.

60W headroom for single high-power endpoints

The 60W budget comfortably drives one 10G passive PoE device such as a multi-radio access point or PTZ camera over full-length copper. It runs out when a second device is daisy-chained or when the attached load exceeds 1.11A at 54V. The injector provides no power budget for additional ports or downstream switches.

Highlights

  • Delivers up to 60 W of power for demanding passive PoE devices
  • Supports 10 Gbps data rates over a single RJ-45 connection
  • Compact wall-mountable design measuring 4.9" × 2.3" × 1.4" for flexible placement
  • Compliant with CE, FCC, BSMI, KC and multiple IEEE 802.3 standards for broad compatibility
  • Includes power cord and installation guide for immediate deployment

Specifications

No published specifications for this item yet.

Questions about this item

What are the dimensions of the wall-mountable adapter?

The adapter measures 1.4 inches high, 4.9 inches wide and 2.3 inches deep, and includes a wall-mountable form factor for fixed installation.

How is the passive PoE injector connected and what is a common wiring mistake?

Connect the power cord, link the LAN cable to the Input RJ-45 port, then run a single Ethernet cable from the Output RJ-45 port to the powered device; a common error is plugging the device into the Input port instead of the Output port.

Which power components may need replacement after extended use?

The external power cord and the internal power supply circuitry delivering 54 V DC at 1.11 A for 60 W output are the parts most likely to require replacement over time.
