Small white rectangular box with Ethernet, USB and Micro USB ports

TP-Link

TP-Link OC200 Omada Cloud Controller network antenna

SKU CH-FWR2-CNB9D

Centralises management for up to 100 Omada access points with cloud access, captive portal and dual Ethernet ports

  • Centralised Omada management from anywhere via free cloud access
  • Control up to 100 access points from a single device
  • Dual 10/100 Mbps Ethernet ports for wired connectivity
  • Powered by 802.3af/at PoE or Micro USB 5 V
  • Compact 1 W design operates from 0 °C to 40 °C

Centralised Omada Management

The TP-Link OC200 Omada Cloud Controller delivers centralised management for up to one hundred Omada EAP access points. It provides real-time monitoring, graphical traffic analysis, captive portal creation, scheduled reboots and batch firmware upgrades. Free cloud access allows administrators to manage the network remotely via the Omada app.

Replaces Standalone AP Configuration

This controller replaces the need to configure each access point individually through its own web interface. The jump is worthwhile when an installation grows beyond a handful of EAPs and requires unified policies, load balancing, band steering, airtime fairness and beamforming across the entire wireless estate.

Limited to Fast Ethernet Uplink

The two Ethernet ports operate at 10/100 Mbps, capping wired backhaul throughput to Fast Ethernet speeds. Power is supplied via 802.3af/at PoE or a Micro USB connection requiring at least one ampere at five volts. The USB 2.0 port serves only for configuration backup, not for additional network interfaces.

Highlights

  • Centralised Omada management from anywhere via free cloud access
  • Control up to 100 access points from a single device
  • Dual 10/100 Mbps Ethernet ports for wired connectivity
  • Powered by 802.3af/at PoE or Micro USB 5 V
  • Compact 1 W design operates from 0 °C to 40 °C

Specifications

BrandTP-Link
ModelOC200

Questions about this item

What ports and power options does the OC200 need for mounting?

The controller has two 10/100 Mbps Ethernet ports, one USB 2.0 port for backup, and a Micro USB port for 5 V / 1 A power; it also accepts 802.3af/at PoE.

What is the common setup mistake when powering the OC200?

Users often forget the Micro USB port requires a 5 V supply rated at least 1 A, so an under-powered adapter causes unstable operation.

What ongoing care does the OC200 need after deployment?

Keep the unit in 0–40 °C ambient temperature with 10–90 % non-condensing humidity and use the USB 2.0 port for periodic configuration backups.
