Transparent 92mm square case fan with blue LED ring and attached speed control knob

Thermaltake

Thermaltake AF0035 92mm Blue LED case fan with speed control knob

SKU CH-0E7Q-RKGT7 MPN AF0035

A 92mm case fan delivers up to 47.0 CFM airflow with a blue LED and manual speed knob

  • Fan Counts1 Fan
  • Fan ControllerNo Controller
  • TypeCase Fan
  • CompatibilityCase
  • Fan Size92mm
  • Fan Thickness25mm
  • Adjustable speed via built-in knob for balanced cooling and quietness
  • Blue LED illumination adds visible style inside transparent cases
  • 1300 to 2500 RPM delivers up to 47.0 CFM airflow
  • Hybrid ball and sleeve bearing rated for 50000 hours MTBF
  • Low 18.6 to 28.0 dBA noise maintains a peaceful workspace

92mm Blue LED Case Fan

The Thermaltake AF0035 is a 92mm case fan with transparent frame and built-in blue LEDs. It runs at 1300 to 2500 RPM and delivers up to 47.0 CFM of airflow. A 4-pin connector supplies 12 V power at 0.30 A. A bundled speed-control knob lets you adjust RPM manually for the desired balance of cooling and noise.

Builders Who Need Manual Speed Control

This fan suits builders who want a single 92mm unit with an external knob for on-the-fly speed changes and blue accent lighting. It is not suited for systems that require PWM motherboard control, fan arrays larger than one unit, or colour schemes other than blue. Buyers needing automated temperature curves should look at PWM-only alternatives.

1 Ball 1 Sleeve Hybrid Bearing

The hybrid bearing combines one ball and one sleeve element rated for 50000 hours at 25°C. It supports the 1300 to 2500 RPM range while keeping noise between 18.6 and 28.0 dBA. Vibration-dampening soft mounts are included to reduce transmitted resonance. This bearing choice determines long-term reliability and acoustic profile.

Highlights

  • Adjustable speed via built-in knob for balanced cooling and quietness
  • Blue LED illumination adds visible style inside transparent cases
  • 1300 to 2500 RPM delivers up to 47.0 CFM airflow
  • Hybrid ball and sleeve bearing rated for 50000 hours MTBF
  • Low 18.6 to 28.0 dBA noise maintains a peaceful workspace

Specifications

BrandThermaltake
ModelAF0035
Fan Counts1 Fan
Fan ControllerNo Controller
TypeCase Fan
CompatibilityCase
Fan Size92mm
Fan Thickness25mm
Bearing Type1 Ball, 1 Sleeve
RPM1,300 - 2,500 RPM
Air FlowMax. Air Flow: 47.0 CFM
Noise Level18.6 - 28.0 dBA
Power Connector4 Pin
ColorTransparent
LEDBlue
FeaturesFan Speed Control: Speed Control Knob
MTBF: 50,000 hrs @ 25°C
Max. Air Pressure: 2.70 mmH2O
Rated Voltage: 12 V
Started Voltage: <= 9 V
Rated Current: 0.30 A
Power Input: 3.60 W
Weight: 76 g
Dimensions92 x 92 x 25 mm
Shipping weight0.11 kg
Package size146 × 95 × 32 mm

Questions about this item

How do I install the 92mm AF0035 fan and what step is often missed?

Mount the fan using the four corner holes with the included vibration-dampening soft mounts, then plug the 4-pin connector into a motherboard header; the step often missed is fitting the soft mounts instead of hard screws, which keeps noise down.

What maintenance or replacement will the AF0035 need over time?

The hybrid bearing is rated for 50000 hours at 25°C; after that the fan may become noisy or stop spinning, so plan to replace the unit once it reaches that service life.

What limit appears first when the AF0035 runs continuously at full speed?

At 2500 RPM the noise reaches 28.0 dBA and the motor draws 3.60 W, so acoustic comfort is the first constraint you hit under sustained load.
